Huber L
The Huber L is a tractor produced by Huber. It is equipped with a 334 ci 5.5 L engine. Operating weight: 3700 lbs 1678 kg.
Fuel & Capacities
Gasoline
Operating Weight
3700 lbs
1678 kg
Huber L Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1936 - 1941
Modern Farmer SeriesStandard-tread tractor |
|---|---|
1936 - 1941 | |
Modern Farmer Series | |
Standard-tread tractor | |
Production | |
|---|---|
Manufacturer | Huber |
Standard-tread tractor | |
Built in Marion, Ohio, USA | |
Variants | |
|---|---|
L | standard |
LC | row-crop |
Huber L Engine | |
|---|---|
Waukesha 5.5L 4-cyl gasoline | |
Engine details ...  |
Huber L Transmission | |
|---|---|
gear | |
Transmission details ...  |
Huber L Power | |
|---|---|
Plows | 3 |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Weight | 3700 lbs
1678 kg |
Full dimensions and tires ...  | |
Belt Pulley | |
|---|---|
Diameter | 17 inches
43 cm |
Width | 7.375 inches
18 cm |
RPM | 705 |
Speed | 2600 ft/min
792.48 meters/min |
Engine
Engine Detail — 334 ci / 5.5 L Gasoline
Manufacturer | Waukesha VIK |
Fuel Type | Gasoline |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 334 ci
5.5 L |
Bore/Stroke | 4.50x5.25 inches
114 x 133 mm |
Air cleaner | oil bath |
Transmission
Transmission — gear
Type | gear |
Dimensions
Huber L Tires |
|---|
Dimensions | |
|---|---|
Length | 123.5 inches
313 cm |
Width | 60 inches
152 cm |
Height | 57.5 inches
146 cm |
Weight | 3700 lbs
1678 kg |
Photos
Huber L
