International Harvester 1255
The International Harvester 1255 is a tractor produced by International Harvester. It is equipped with a 358 ci 5.9 L engine. The rated power output is 125 hp 93.2 kW. Transmission: 12 forward and 5 reverse. Operating weight: 12215 lbs 5540 kg.
Engine Power
125 hp
93.2 kW
Fuel & Capacities
52.8 gal
199.8 L
Transmission
12 forward and 5 reverse
Operating Weight
12215 lbs
5540 kg
International Harvester 1255 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1979 - 1985 | 1979 - 1985 |
|---|
Production | |
|---|---|
Manufacturer | International Harvester |
Built in Neuss, Germany | |
International Harvester 1255 Engine | |
|---|---|
International Harvester 5.9L 6-cyl diesel | |
Fuel tank | 52.8 gal
199.8 L |
Engine details ...  | |
International Harvester 1255 Power | |
|---|---|
Engine | 125 hp
93.2 kW |
Mechanical | |
|---|---|
Four-wheel drive |
Hydraulics | |
|---|---|
Pump flow | 13.2 gpm
50.0 lpm |
Tractor hitch | |
|---|---|
Rear lift | 10143 lbs
4600 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540, 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 110.24 inches
280 cm |
Weight | 12215 lbs
5540 kg |
Front tire | 14.9R28 |
Rear tire | 20.8R38 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Field Force published in 1981, by International Harvester |
Engine
Engine Detail — 358 ci / 5.9 L Diesel
Manufacturer | International Harvester |
Configuration | turbocharged diesel, 6-cylinder, liquid-cooled |
Displacement | 358 ci
5.9 L |
Bore/Stroke | 3.875x5.0625 inches
98 x 129 mm |
Power | 125 hp
93.2 kW |
Rated RPM | 2200 |
Transmission
Transmission options | |
|---|---|
20-speed | |
12-speed |
Transmission — 20 forward and 9 reverse
Gears | 20 forward and 9 reverse |
Transmission — 12 forward and 5 reverse
Gears | 12 forward and 5 reverse |
Dimensions
International Harvester 1255 Tires | |
|---|---|
Ag front | 14.9R28 |
Ag rear | 20.8R38 |
Dimensions | |
|---|---|
Wheelbase | 110.24 inches
280 cm |
Length | 186.61 inches
473 cm |
Height | 115.75 inches
294 cm |
Weight | 12215 lbs
5540 kg |
Photos
International Harvester 1255 row-crop tractor.
