International Harvester 1486B
The International Harvester 1486B is a tractor produced by International Harvester. It is equipped with a 436 ci 7.1 L engine. The rated power output is 167 hp 124.5 kW. Transmission: two-speed power shift. Operating weight: 13371 lbs 6065 kg.
Engine Power
167 hp
124.5 kW
Transmission
two-speed power shift
Operating Weight
13371 lbs
6065 kg
International Harvester 1486B Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1981 - 1982
86B SeriesRow-Crop tractor |
|---|---|
1981 - 1982 | |
86B Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | International Harvester |
Row-Crop tractor | |
Built in Geelong, Australia | |
Total built | 64 |
International Harvester 1486B Engine | |
|---|---|
International Harvester 7.1L 6-cyl diesel | |
Engine details ...  |
International Harvester 1486B Transmission | |
|---|---|
16-speed Torque Amplifier | |
Transmission details ...  |
International Harvester 1486B Power | |
|---|---|
Engine | 167 hp
124.5 kW |
PTO (claimed) | 125 hp
93.2 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | electro-hydraulic rear |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard. | |
Hydraulics | |
|---|---|
Type | open center |
Tractor hitch | |
|---|---|
Rear Type | III/II |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 1000@2300 |
Dimensions & Tires | |
|---|---|
Weight | 13371 lbs
6065 kg |
Front tire | 11.00-16 |
Rear tire | 24.5-32 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
International Harvester Australia: Geelong Works by Sarah Tomac* | |
International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick | |
Technical Annual published in 1983, by Power Farming | |
*Publication contains known errors. |
Engine
Engine Detail — 436 ci / 7.1 L Diesel
Manufacturer | International Harvester DT-436 |
Configuration | turbocharged diesel, 6-cylinder, liquid-cooled inline |
Displacement | 436 ci
7.1 L |
Bore/Stroke | 4.30x5.00 inches
109 x 127 mm |
Power | 167 hp
124.5 kW |
Rated RPM | 2600 |
Starter type | electric |
Transmission
Transmission — two-speed power shift
Transmission | two-speed power shift |
Type | Torque Amplifier |
Gears | 16 forward and 4 reverse |
Clutch | hydraulic cerametallic disc |
Dimensions
International Harvester 1486B Tires | |
|---|---|
Ag front | 11.00-16 |
Ag rear | 24.5-32 |
Dimensions | |
|---|---|
Length | 168.1 inches
426 cm |
Width | 102 inches
259 cm |
Height (cab) | 114.2 inches
290 cm |
Weight | 13371 lbs
6065 kg |
Ground clearance | 15.4 inches
39 cm |
Photos
International Harvester 1486B tractor photo
