J.I. Case 1010
The J.I. Case 1010 is a tractor produced by J I Case. It is equipped with a 382 ci 6.3 L engine. The rated power output is 100 hp 74.6 kW. Transmission: Terramatic. Drive type: crawler. Operating weight: 17105 lbs 7758 kg.
Engine Power
100 hp
74.6 kW
Drive & Traction
crawler
Fuel & Capacities
Diesel
Transmission
Terramatic
Operating Weight
17105 lbs
7758 kg
J I Case J.I. Case 1010 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1958 - 1964
Agricultural Crawler tractor |
|---|---|
1958 - 1964 | |
Agricultural Crawler tractor | |
Production | |
|---|---|
Manufacturer | J.I. Case |
Agricultural Crawler tractor | |
Built in Churubusco, Indiana, USA | |
Variants | |
|---|---|
1000 | industrial crawler |
1010 | ag crawler |
J.I. Case 1010 Engine | |
|---|---|
Continental 6.3L 4-cyl diesel | |
Engine details ...  |
J.I. Case 1010 Transmission | |
|---|---|
4-speed power shift | |
Transmission details ...  |
J.I. Case 1010 Power | |
|---|---|
Engine (gross) | 100 hp
74.6 kW |
Plows | 6 |
Drawbar (tested) | 52.91 hp
39.5 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Drive | crawler |
Hydraulic disc brakes | |
Open operator station. | |
Hydraulics | |
|---|---|
Pump flow | 30 gpm
113.6 lpm |
Dimensions & Tracks | |
|---|---|
Wheelbase | 79 inches
200 cm |
Weight | 17105 lbs
7758 kg |
16-inch tracks | |
Full dimensions and tracks ...  | |
References | |
|---|---|
 | |
Case Agricultural Crawlers published in 1959, by J.I. Case | |
Case Tool Bar Dozer published in 1958, by J.I. Case | |
J.I. Case presents published in 1957 |
Engine
Engine Detail — 382 ci / 6.3 L Diesel
Manufacturer | Continental JD-382 |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 382 ci
6.3 L |
Bore/Stroke | 4.50x6.00 inches
114 x 152 mm |
Power (gross) | 100 hp
74.6 kW |
Air cleaner | oil bath |
Compression | 15.5:1 |
Rated RPM | 2000 |
Torque | 276 lb-ft
374.3 Nm |
Torque RPM | 1200 |
Starter | electric |
Starter volts | 24 |
Transmission
Transmission — Terramatic
Transmission | Terramatic |
Type | power shift |
Gears | 4 forward and reverse |
Clutch | hydraulic disc |
 | |
Dimensions
J.I. Case 1010 Tracks | |
|---|---|
Width | 16 inches
40 cm |
Dimensions | |
|---|---|
Wheelbase | 79 inches
200 cm |
Length | 140.1 inches
355 cm |
Width | 76 inches
193 cm |
Height (steering wheel) | 72.625 inches
184 cm |
Operating weight | 17105 lbs
7758 kg |
Gauge | 60 inches
152 cm |
Tests
Nebraska Tractor Test 712 | |
|---|---|
Diesel 4-speed crawler
August 14 - 28, 1959
Link: Nebraska Tractor Test 712 file | |
Drawbar performance | |
Max power | 52.91 hp
39.5 kW |
Fuel use | 6.3 gal/hour
23.8 l/hour |
Gear 2 used for power test. | |
Max pull | 15260 lbs
6921 kg |
Gear 1 used for pull test. | |
