j i case 2470
 | 1972 - 1979
Four-wheel Drive (4WD) tractor | 1972 - 1979 | Four-wheel Drive (4WD) tractor |
|---|---|---|---|
1972 - 1979 | |||
Four-wheel Drive (4WD) tractor | |||
1972 - 1979 | |
|---|---|
Four-wheel Drive (4WD) tractor |
Nebraska Tractor Test 1114 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 1114 | |
|---|---|
Diesel 12-speed 4WD
October 25 - 31, 1972
Link: Nebraska Tractor Test 1114 file | |
PTO performance | |
Power at rated engine speed | 174.20 hp
129.9 kW |
Fuel use | 11.4 gal/hour
43.1 l/hour |
Drawbar performance | |
Max power | 150.52 hp
112.2 kW |
Fuel use | 11.3 gal/hour
42.8 l/hour |
Gear 3-2 used for power test. | |
Max pull | 18,050 lbs
8187 kg |
Gear 2-1 used for pull test. | |
