J.I. Case 995

The J.I. Case 995 is a tractor produced by J I Case. It is equipped with a 219.3 ci 3.6 L engine. The rated power output is 62 hp 46.2 kW. Transmission: 12 forward and 4 reverse. Operating weight: 4780 to 5190 pounds.

Overview

	1976 - 1980 Utility tractor
1976 - 1980
Utility tractor

Series map: 1390↑ 1980-1983990995121058.0hp62.0hp-1hp885↓ 1971-1980

Note: the J.I. Case model 995 is the same as the David Brown 995. The following data is from the 995 listing.

Production
Manufacturer	J.I. Case
Utility tractor
Built in Meltham Mills, Huddersfield, England
Original price was $10,500 in 1976

J.I. Case 995 Engine
David Brown 3.6L 4-cyl diesel
Fuel tank	16 gal 60.6 L
Engine details ...

J.I. Case 995 Transmission
12-speed synchromesh
Transmission details ...

J.I. Case 995 Power
Engine (gross)	62 hp 46.2 kW
PTO (claimed)	58 hp 43.3 kW
Drawbar (tested)	48.73 hp 36.3 kW
PTO (tested)	58.77 hp 43.8 kW
Performance test details ...

Mechanical
Two-wheel drive
Final drives	spur gear
Power steering
Hydraulic drum brakes
Open operator station. Quiet Cab optional.

Hydraulics
Type	open center
Pump flow	7.4 gpm 28.0 lpm

Tractor hitch
Rear Type	II/I
Rear lift	2000 lbs 907 kg

Power Take-off (PTO)
Rear PTO	live
Rear PTO Type	540/1000
Engine RPM	540@1800
	1000@2000

Dimensions & Tires
Wheelbase	82 inches 208 cm
Weight	4780 to 5190 pounds
Front tire	7.50-16
Rear tire	13.6/12-36
Full dimensions and tires ...

Electrical
Charging system	alternator
Battery volts	12
Battery AH	96

References
1975 Spring Buyers Guide published by J.I. Case
Time-saving experts published in 1975, by J.I. Case
"Specializing" for Specialists published in 1978, by J.I. Case
Specialization... the payoff in farming published in 1980, by J.I. Case
The new look in farm power published in 1981, by J.I. Case

Engine

Series map: 1390↑ 1980-1983990995121058.0hp62.0hp-1hp885↓ 1971-1980

Note: the J.I. Case model 995 is the same as the David Brown 995. The following data is from the 995 listing.

Engine Detail — 219.3 ci / 3.6 L Diesel

Manufacturer	David Brown
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	219.3 ci 3.6 L
Bore/Stroke	3.94x4.50 inches 100 x 114 mm
Power (gross)	62 hp 46.2 kW
Compression	17:1
Rated RPM	2200
Operating RPM	700-2200
Coolant capacity	14 qts 13.2 L

Transmission

Series map: 1390↑ 1980-1983990995121058.0hp62.0hp-1hp885↓ 1971-1980

Note: the J.I. Case model 995 is the same as the David Brown 995. The following data is from the 995 listing.

Transmission — 12 forward and 4 reverse synchromesh

Type	synchromesh
Gears	12 forward and 4 reverse
Clutch	250mm dry disc
Three gears, plus reverse, in four ranges. Synchronized up-shifts from 1-to-2 and 2-to-3. Synchronized down-shift from 3-to-2.

Dimensions

Series map: 1390↑ 1980-1983990995121058.0hp62.0hp-1hp885↓ 1971-1980

Note: the J.I. Case model 995 is the same as the David Brown 995. The following data is from the 995 listing.

J.I. Case 995 Tires
Ag front	7.50-16
Ag rear	13.6/12-36
Ag front	6.00-19
Ag rear	12.4/11-36
	16.4/14-30

Dimensions
Wheelbase	82 inches 208 cm
Length	126 inches 320 cm
Width	67 inches*Minimum width 170 cm
Height (hood)	58.5 inches 148 cm
Height (cab)	95 inches 241 cm
Clearance (front axle)	21 inches 53 cm
Clearance (drawbar)	16 inches 40 cm
Rear tread	52 to 76 inches 132 to 193 cm

J.I. Case 995 Weight
	4780 lbs 2168 kg
Cab Operating	5190 lbs 2354 kg
Ballasted	9475 lbs 4297 kg

Tests

Series map: 1390↑ 1980-1983990995121058.0hp62.0hp-1hp885↓ 1971-1980

Note: the J.I. Case model 995 is the same as the David Brown 995. The following data is from the 995 listing.

Nebraska Tractor Test 1136
Diesel 12-speed 2WD June 18 - 29, 1973 Link: Nebraska Tractor Test 1136 file
PTO performance
Power at rated engine speed	58.77 hp 43.8 kW
Fuel use	3.7 gal/hour 14.0 l/hour
Power at rated PTO speed	55.33 hp 41.3 kW
Fuel use	3.3 gal/hour 12.5 l/hour
Drawbar performance
Max power	48.73 hp 36.3 kW
Fuel use	3.5 gal/hour 13.2 l/hour
Max pull	7317 lbs 3318 kg
