J.I. Case 610-B

The J.I. Case 610-B is a tractor produced by J I Case. It is equipped with a 164.5 ci 2.7 L engine. Transmission: Case-O-Matic. Operating weight: 4010 lbs 1818 kg.

Fuel & Capacities
13.8 gal 52.2 L
Transmission
Case-O-Matic
Operating Weight
4010 lbs 1818 kg

Overview

J.I. Case 610-B tractor photo
1958 - 1959 600B SeriesUtility tractor 600B Series Utility tractor
Production
Manufacturer
J.I. Case
Utility tractor
Built in Rock Island, Illinois, USA
Total built
744
Variants
610B
standard front
611B
row-crop front
614B
orchard
J.I. Case 610-B Engine
J.I. Case 2.7L 4-cyl gasoline
Engine details ...
J.I. Case 610-B Power
PTO (claimed)
45 hp 33.6 kW
Mechanical
Two-wheel drive
Manual steering
Disc brakes
Open operator station.
Capacity
Fuel
13.8 gal 52.2 L
Hydraulic system
3 gal 11.4 L
Hydraulics
Type
open center
Capacity
3 gal 11.4 L
Pressure
1200 psi 82.7 bar
Tractor hitch
Type
Case Eagle Hitch OptOptional
Power Take-off (PTO)
Rear PTO
independent
Rear PTO Type
540 (1.375)
Engine RPM
541@1970
Dimensions & Tires
Wheelbase
78.5 inches 199 cm
Weight
4010 lbs 1818 kg
Front tire
6.00-16
Rear tire
11-28
Full dimensions and tires ...
Belt Pulley
Diameter
9.25 inches 23 cm
Width
6.4 inches 16 cm
RPM
1360
Speed
3290 ft/min 1002.79 meters/min
Electrical
Ground
positive
Battery volts
12
Battery AH
50
References
610-B references literature
J.I. Case presents published in 1957

Engine

Engine Detail — 164.5 ci / 2.7 L Gasoline

Manufacturer
J.I. Case
Fuel Type
Gasoline
Configuration
4-cylinder, liquid-cooled
Displacement
164.5 ci 2.7 L
Bore/Stroke
3.5625x4.125 inches 90 x 105 mm
Air cleaner
oil bath
Compression
7.26:1
Rated RPM
2250
Starter
electric
Starter volts
12
Coolant capacity
12 qts 11.4 L
Oil capacity
5 qts 4.7 L
Oil change
100 h

Transmission

Transmission options
8-speed torque converter
8-speed shuttle

Transmission — Case-O-Matic

Transmission
Case-O-Matic
Type
torque converter
Gears
8 forward and 2 reverse
Oil capacity
44 qts (gearbox) 41.6 L
16 qts (torque converter) 15.1 L
With 11-28 rear tires and torque converter engaged. Speeds are 25% faster with torque converter locked.
610-B Case-O-Matic torque converter speeds

Transmission — 8 forward and reverse shuttle

Type
shuttle
Gears
8 forward and reverse
Oil capacity
44 qts (gearbox) 41.6 L
16 qts (torque converter) 15.1 L
With 11-28 rear tires and torque converter engaged. Speeds are 25% faster with torque converter locked. Reverse speeds are 24% faster than forward.
610-B shuttle speeds

Dimensions

J.I. Case 610-B Tires
Ag front
6.00-16
Ag rear
11-28
Ag front
7.50-16
Ag rear
10-28
12-28
13-28
Dimensions
Wheelbase
78.5 inches 199 cm
Length
121.5 inches 308 cm
Width
63.3 inches 160 cm
Height (steering wheel)
63.4 inches 161 cm
Weight
4010 lbs 1818 kg
Front tread
52 inches 132 cm
Rear tread
48 to 86 inches 121 to 218 cm

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for J I Case J.I. Case 610-B.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

J I Case J.I. Case 610-B Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for J I Case J.I. Case 610-B.

Converted Equivalents:

Horsepower (HP)0 hp
Kilowatts (kW)0 kW
Metric Horsepower (PS / CV)0 PS
