John Deere 2032R

The John Deere 2032R is a tractor produced by John Deere. It is equipped with a 100 ci 1.6 L engine. The listed engine power is Diesel (listed): 32 hp / 23.9 kW; Diesel (gross): 31.7 hp / 23.6 kW. Transmission: infinite forward and reverse (2-range). Operating weight: 1973 lbs 894 kg.

Overview

	2013 - 2025 Model year 2013-20162017-2025 2R SeriesCompact Utility tractor 2R Series Compact Utility tractor

Production
Manufacturer	John Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
Original price	$18,595 (2013 )
	$19,339 (2014 )

John Deere 2032R Engine
Yanmar 1.6L 3-cyl diesel
Engine details ...

John Deere 2032R Transmission
hydrostatic
Transmission details ...

John Deere 2032R Power
Engine (gross)	31.7 hp 23.6 kW
Engine	32 hp 23.9 kW
PTO (claimed)	23.5 hp 17.5 kW

Mechanical
Four-wheel drive
Final drives	spur gear
Differential lock	standard
Power steering
Wet disc brakes
Two-post folding ROPS.

Capacity
Fuel	7.1 gal 26.9 L
Hydraulic system	3.9 gal 14.8 L
Front axle	0.9 qts 0.9 L

Hydraulics
Type	open center
Capacity	3.9 gal 14.8 L
Pressure	2421 psi 166.9 bar
Mid valves	2
Pump flow	5.0 gpm 18.9 lpm
Total flow	10.5 gpm 39.7 lpm
Steering flow	5.5 gpm 20.8 lpm

Tractor hitch
Rear Type	I
Control	position control
Rear lift (at ends)	1433 lbs 650 kg
Rear lift (at 24"/610mm)	1250 lbs 567 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	wet disc
Rear PTO Type	540
Mid PTO	independent
Mid PTO Type	2100

Dimensions & Tires
Wheelbase	65.2 inches 165 cm
Weight	1973 lbs 894 kg
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	40
Charging volts	12
Battery CCA	500
Battery volts	12

References
2R Series published in 2013, by John Deere
2R Series published in 2015, by John Deere

Engine

Engine Detail — 100 ci / 1.6 L Diesel

Manufacturer	Yanmar 3TNV88
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	100 ci 1.6 L
Bore/Stroke	3.465x3.543 inches 88 x 90 mm
Power	32 hp 23.9 kW
Rated Power (gross)	31.7 hp 23.6 kW
Fuel system	direct injection
Air cleaner	dual stage dry
Compression	19.1:1
Rated RPM	2500
Operating RPM	1000-2650
Starter	electric
Starter volts	12
Coolant capacity	4.2 qts 4.0 L
Oil capacity	3.6 qts 3.4 L
Oil change	200 h

Transmission

Transmission — infinite forward and reverse (2-range) hydrostatic

Type	hydrostatic
Gears	infinite forward and reverse (2-range)
Oil capacity	15.6 qts 14.8 L
Oil type	Deere Hy-Gard

	Deere Hy-Gard

Dimensions

John Deere 2032R Tires
Lawn/turf front	24x8.5-14
Lawn/turf rear	36x14.00-15
Industrial front	23x8.5-12
Industrial rear	14-17.5

Dimensions
Wheelbase	65.2 inches 165 cm
Length	108.9 inches 276 cm
Width	47.1 inches (min) 119 cm
	55.6 inches 141 cm
Height (hood)	53.3 inches 135 cm
Height (ROPS)	89.7 inches 227 cm
Height (Folded ROPS)	67.5 inches 171 cm
Clearance (front axle)	13 inches 33 cm
Front axle	Flange
Front tread	32.7 inches 83 cm

John Deere 2032R Weight
Shipping	1973 lbs 894 kg
Max Drawbar	562 lbs 254 kg
Max front axle	1940 lbs 879 kg
Max rear axle	2426 lbs 1100 kg

Attachments

Attachment overview
62" mid-mount mower deck
72" mid-mount mower deck
Snowblower
Blade
Front-end loader
Backhoe

John Deere 46 Backhoe
Backhoe type	John Deere 46 Backhoe
2-Foot flat digging depth	78 inches 198 cm
Bucket force	2840 lbs 1288 kg
