John Deere 2650

The John Deere 2650 is a tractor produced by John Deere. It is equipped with a 239.2 ci 3.9 L engine. The listed engine power is Diesel (listed): 78 hp / 58.2 kW; Diesel (listed): 4 hp / 3.0 kW. Transmission: Hi-Lo. Operating weight: 7694 to 8378 pounds.

Overview

	1987 - 1994 Utility tractor

Production
Manufacturer	John Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany

John Deere 2650 Engine
John Deere 3.9L 4-cyl diesel
Fuel tank	22.2 gal 84.0 L
	35.9 gal*With optional 52L tank. 135.9 L
Engine details ...

John Deere 2650 Transmission
16-speed two-speed power shift
Transmission details ...

John Deere 2650 Power
Engine	78 hp 58.2 kW

Mechanical
Two- or four-wheel drive
Final drives	planetary
Power steering
Wet disc brakes
ROPS. Sound-Gard and CC2 cab optional.

Hydraulics
Type	closed-center constant pressure
Pressure	2756 psi 190.0 bar
Pump flow	11.6 gpm 43.9 lpm

Tractor hitch
Rear Type	II
Control	position and draft control
Rear lift (at 24"/610mm)	4134 lbs 1875 kg
Front Hitch	II
Front lift	1742 lbs 790 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	hydraulic wet disc
Rear PTO Type	540/1000
Engine RPM	540@2070
	1000@2172
Front PTO	independent
Clutch	hydraulic wet disc
Front PTO Type	1000
Engine RPM	1000@2172

Dimensions & Tires
2WD Wheelbase	89.2 inches 226 cm
4WD Wheelbase	90 inches 228 cm
Weight	7694 to 8378 pounds
Front tire	7.50-18
2WD Rear tire	13.6R38
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	44
Batteries	2
Battery volts	12
Battery AH	55

References
Operator's Manual 2250, 2450 and 2650 Tractors published in 1992, by John Deere
Operator's Manual 2650 and 2850 Tractors published in 1992, by John Deere
24650 Traktor published in 1986, by John Deere

Engine

Engine Detail — 239.2 ci / 3.9 L Diesel

Manufacturer	John Deere
Configuration	turbocharged diesel, 4-cylinder, liquid-cooled
Displacement	239.2 ci 3.9 L
Bore/Stroke	4.19x4.33 inches 106 x 110 mm
Power	78 hp 58.2 kW
Air cleaner	dry
Rated RPM	2300
Starter volts	12
Starter power	4 hp 3.0 kW
Coolant capacity	15.9 qts 15.0 L

Transmission

Transmission — Hi-Lo

Transmission	Hi-Lo
Type	two-speed power shift
Gears	16 forward and 8 reverse
Clutch	cerametallic disc
With 13.6-38 rear tires.

Dimensions

John Deere 2650 Tires
2WD Standard tires (ag)	Front: 7.50-18. Rear: 13.6R38
4WD Standard tires (ag)	Front: 11.2-28. Rear: 13.6R38

Dimensions
2WD Wheelbase	89.2 inches 226 cm
4WD Wheelbase	90 inches 228 cm
Length	165.1 inches 419 cm
Width	80.8 inches 205 cm
Height (cab)	104.8 inches 266 cm
2WD Shipping weight	7694 lbs 3489 kg
4WD Shipping weight	8378 lbs 3800 kg
2WD Clearance (front axle)	25.8 inches 65 cm
4WD Clearance (front axle)	19.5 inches 49 cm
2WD Front tread	53.5 to 79.1 inches 135 to 200 cm
4WD Front tread	59.1 to 79.1 inches 150 to 200 cm
Rear tread	59.1 to 78.7 inches 150 to 199 cm
