John Deere 3100
The John Deere 3100 is a tractor produced by John Deere. It is equipped with a 179 ci 2.9 L engine. The listed engine power is Diesel (net): 55 hp / 41.0 kW. Transmission: Twinshift. Operating weight: 6548 lbs 2970 kg.
Engine Power
Diesel (net): 55 hp / 41.0 kW
Fuel & Capacities
30.4 gal
115.1 L
Transmission
Twinshift
Operating Weight
6548 lbs
2970 kg
Overview
 | 1995 - 1998
Utility tractorRenault built
Utility tractor
Renault built |
|---|
Production | |
|---|---|
Distributor | John Deere |
Manufacturer | Renault |
Utility tractor | |
Built in Le Mans, France | |
John Deere 3100 Engine | |
|---|---|
John Deere 2.9L 3-cyl diesel | |
Fuel tank | 30.4 gal
115.1 L |
Engine details ...  | |
John Deere 3100 Power | |
|---|---|
Engine (net) | 55 hp
41.0 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Wet disc brakes | |
Cab standard with heater. |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2611 psi
180.0 bar |
Pump flow | 13.7 gpm
51.9 lpm |
Steering flow | 7 gpm
26.5 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | lower-link draft sensing |
Rear lift | 6317 lbs
2865 kg |
8430 lbsOptOptional
3823 kg | |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | mechanical |
Rear PTO Type | 540 |
540/540E OptOptional | |
540/1000 OptOptional | |
Dimensions & Tires | |
|---|---|
Weight | 6548 lbs
2970 kg |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 65 |
Battery volts | 12 |
Battery AH | 105 |
References | |
|---|---|
 | |
New John Deere 3000 Series Tractors published in 1994 |
Engine
Engine Detail — 179 ci / 2.9 L Diesel
Manufacturer | John Deere 3029D |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Displacement | 179 ci
2.9 L |
Bore/Stroke | 4.19x4.33 inches
106 x 110 mm |
Rated Power (net) | 55 hp
41.0 kW |
Rated RPM | 2280 |
Torque | 151 lb-ft
204.8 Nm |
Torque RPM | 1500 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
10-speed synchronized | |
20-speed synchronized | |
20-speed two-speed power shift |
Transmission — 10 forward and reverse synchronized
Type | synchronized |
Gears | 10 forward and reverse |
Five synchronized gears in two ranges with synchronized shuttle. | |
 | |
Transmission — 20 forward and reverse synchronized
Type | synchronized |
Gears | 20 forward and reverse |
Optional mechanical splitter doubles the numbers of speeds in the base transmission. Clutch must be used with mechanical splitter. Also available with an optional creeper range, providing 30 total speeds in each direction. | |
 | |
Transmission — Twinshift
Transmission | Twinshift |
Type | two-speed power shift |
Gears | 20 forward and reverse |
The Twinshift provides a push-button splitter to the base transmission. | |
 | |
Dimensions
John Deere 3100 Tires |
|---|
Dimensions | |
|---|---|
Width | 73.2 inches
185 cm |
Height (cab) | 95.4 inches
242 cm |
Shipping weight | 6548 lbs
2970 kg |
Recommended Implements & Sizing Guide
Engineering recommendations for John Deere 3100 based on its 55 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 3 to 4 Bottom (16")3 - 4 铧 (40 cm) | Heavy Duty | Suitable for medium loam and stubble turnover. |
Rotary Cutter / MowerMowing & Clearing | 6 ft (72 in)1.8 m | Medium Duty | Medium pasture clearing; rear slip-clutch recommended. |
Rotary TillerSeedbed Prep | 66 to 72 in165 - 180 cm | Medium Duty | Standard utility tiller; slip clutch protection required. |
Disc HarrowSecondary Tillage | 7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙 | Medium Duty | Field leveling and clod breaking behind plows. |
Hay BalerHay & Forage | Small Square Baler (14x18")小方捆打捆机 (36x46 cm) | Medium Duty | Classic 2-string baler for horse and small livestock hay. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for John Deere 3100.
Estimated Continuous Field Runtime: 10.6 hrs
Approximately 10.6 hours of continuous field operation at ~75% rated power on a full tank (30.4 gal / 115.1 L).
Estimated 75% Load Fuel Burn~2.9 gal/hr (10.8 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
John Deere 3100 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for John Deere 3100.
Converted Equivalents:
Horsepower (HP)55 hp
Kilowatts (kW)41 kW
Metric Horsepower (PS / CV)55.8 PS
Direct Competitor Comparison
Compare John Deere 3100 against same-era industry alternatives in the same horsepower class.
Current Model
John Deere
John Deere 3100
Engine Power:Diesel (net): 55 hp / 41.0 kW
★ Baseline Reference
