John Deere 1600 Turbo

The John Deere 1600 Turbo is a tractor produced by John Deere Lawn Tractors. It is equipped with a 1994 cc 121.7 ci engine. The rated power output is 56 hp 41.8 kW. Transmission: Kanzaki. Drive type: 4x4 MRWD 4WD. Operating weight: 3950 lbs 1791 kg.

Overview

	2002 - 2006 Front-mount mower
2002 - 2006
Front-mount mower

2002 - 2006
Front-mount mower

Production
Manufacturer	John Deere
Front-mount mower
Built in Fuquay-Varina, North Carolina, USA
Original price was $48,699 in 2003

John Deere 1600 Turbo Engine
64HP Yanmar 1994cc 4-cyl diesel
Fuel tank	15 gal 56.8 L
Engine details ...

John Deere 1600 Turbo Transmission
hydrostatic
Transmission details ...

Mechanical
Drive	4x4 MRWD 4WD
Final drives	planetary
Differential lock	mechanical front
Power steering
Wet disc brakes
Two-post ROPS.

Power Take-off (PTO)
Front PTO	independent

Dimensions & Tires
Wheelbase	60 inches 152 cm
Weight	3950 lbs 1791 kg
Front tire	26x12-12
Rear tire	20x10-8
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	55
Battery CCA	650
Battery volts	12

References
1600 Turbo Wide-Area Mower published in 2002, by John Deere
Operator's Manual Wide Area Mower 1600 Turbo (OMTCU16064) published in 2002
Commercial Mowing and Portable Power Equipment published in 2003, by John Deere
Commercial Mowing and Portable Power Equipment published in 2004, by John Deere
1400 and 1500 Series II / 1600 Series Mowers 2004 published by John Deere
Commercial Mowing Equipment published in 2006, by John Deere

Engine

	2002 - 2006 Front-mount mower
2002 - 2006
Front-mount mower

2002 - 2006
Front-mount mower

Engine Detail — 1994 cc / 121.7 ci Diesel

Manufacturer	Yanmar 4TNE84T
Configuration	turbocharged diesel, 4-cylinder, liquid-cooled horizontal-shaft inline
Displacement	1994 cc 121.7 ci
Bore/Stroke	3.31x3.54 inches 84 x 90 mm
Power (net)	56 hp 41.8 kW
Power (gross)	64 hp 47.7 kW
Air cleaner	dry
Compression	18:1
Rated RPM	3000
Starter	electric
Starter volts	12
Coolant capacity	10 qts 9.5 L

Transmission

	2002 - 2006 Front-mount mower
2002 - 2006
Front-mount mower

2002 - 2006
Front-mount mower

Transmission — Kanzaki

Transmission	Kanzaki
Type	hydrostatic
Gears	infinite forward and reverse (2-range)

Dimensions

	2002 - 2006 Front-mount mower
2002 - 2006
Front-mount mower

2002 - 2006
Front-mount mower

John Deere 1600 Turbo Tires
Lawn/turf front	26x12-12
Lawn/turf rear	20x10-8

Dimensions
Wheelbase	60 inches 152 cm
Length	132 inches 335 cm
Width	84 inches (transport) 213 cm
	134 inches (mowing) 340 cm
Height (ROPS)	77 inches 195 cm
Weight	3950 lbs 1791 kg

Attachments

	2002 - 2006 Front-mount mower
2002 - 2006
Front-mount mower

2002 - 2006
Front-mount mower

Attachment overview
62" front-mount mower deck
42" side-mount mower deck
