John Deere D155
The John Deere D155 is a tractor produced by John Deere Lawn Tractors. It is equipped with a 721 cc 44 ci engine. The rated power output is 24 hp 17.9 kW. Transmission: Tuff Torq T40. Operating weight: 483 lbs*Weight with mower deck. 219 kg.
Engine Power
24 hp
17.9 kW
Fuel & Capacities
2.4 gal
9.1 L
Transmission
Tuff Torq T40
Operating Weight
483 lbs*Weight with mower deck.
219 kg
John Deere Lawn Tractors John Deere D155 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2015 - 2017
D100 SeriesLawn tractor |
|---|---|
2015 - 2017 | |
D100 Series | |
Lawn tractor | |
Production | |
|---|---|
Manufacturer | John Deere |
Lawn tractor | |
Built in Greeneville, Tennessee, USA | |
John Deere D155 Engine | |
|---|---|
24HP Briggs & Stratton 721cc 2-cyl gasoline | |
Fuel tank | 2.4 gal
9.1 L |
Engine details ...  | |
John Deere D155 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Weight | 483 lbs
219 kg |
Front tire | 15x6-6 |
Rear tire | 20x10-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 16 |
Battery volts | 12 |
References | |
|---|---|
 | |
Riding Lawn Tractors published in 2015, by John Deere | |
Riding Lawn Tractors published in 2017, by John Deere | |
Riding Lawn Tractors published in 2016, by John Deere | |
 | |
Operator's Manual D100 Series (OMGX25410) published in 2014 | |
Operator's Manual D100 Series (OMGX26097) published in 2015 | |
Operator's Manual D100 Series (OMUC11804) published in 2016 |
Engine
Engine Detail — 721 cc / 44 ci Gasoline
Manufacturer | Briggs & Stratton 44 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical-shaft V-Twin |
Displacement | 721 cc
44 ci |
Bore/Stroke | 3.12x2.89 inches
79 x 73 mm |
Power (gross) | 24 hp
17.9 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — Tuff Torq T40
Transmission | Tuff Torq T40 |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
Oil change | sealed unit, owner service is not recommended |
 | |
Dimensions
John Deere D155 Tires | |
|---|---|
Lawn/turf front | 15x6-6 |
Lawn/turf rear | 20x10-8 |
Dimensions | |
|---|---|
Length | 69.5 inches
176 cm |
Height | 44.5 inches
113 cm |
Weight | 483 lbs*Weight with mower deck.
219 kg |
Attachments
Attachment overview | |
|---|---|
48" mid-mount mower deck | |
Snowblower | |
Blade |
48" Mower deck | |
|---|---|
Type | mid-mount John Deere |
3-blade with manual lift | |
Cutting width | 48 inches
121 cm |
Overall width | 60.8 inches
154 cm |
Cut height | 1 to 4 inch
2 to 10 cm |
Photos
John Deere D155 tractor photo
