John Deere D160

The John Deere D160 is a tractor produced by John Deere Lawn Tractors. It is equipped with a 724 cc 44.2 ci engine. The rated power output is 25 hp 18.6 kW. Transmission: Tuff Torq HD K46. Operating weight: 525 lbs*Weight with mower deck. 238 kg.

Overview

	2011 - 2017 D100 SeriesLawn tractor
2011 - 2017
D100 Series
Lawn tractor

Production
Manufacturer	John Deere
Lawn tractor
Built in Greeneville, Tennessee, USA
Original price	$2,599 (2011 )
	$2,349 (2015 )

John Deere D160 Engine
25HP Briggs & Stratton 724cc 2-cyl gasoline
Fuel tank	4 gal 15.1 L
	2.4 gal*California model 9.1 L
Engine details ...

John Deere D160 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Mechanical shoe on transaxle brakes
Open operator station. Adjustable 15-inch tall seat with 5.5-inches of travel in ten positions and lumbar adjustment. Fender-mounted cup holder. Optional nylon sunshade canopy or snow enclosure. Optional 12-volt power outlet.

Power Take-off (PTO)
Front PTO	independent
Clutch	electric

Dimensions & Tires
Wheelbase	48.9 inches 124 cm
Weight	525 lbs 238 kg
Front tire	16x6.5-8
Rear tire	22x9.5-12
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	16
Battery volts	12
Battery Group	U1

References
Riding Lawn Tractors published in 2015, by John Deere
Riding Lawn Tractors published in 2017, by John Deere
Riding Lawn Tractors published in 2016, by John Deere
Operator's Manual D100 Series (OMGX24147) published in 2011
Operator's Manual D100 Series (OMGX24230) published in 2012
Operator's Manual D100 Series (OMGX24920) published in 2013
Operator's Manual D100 Series (OMGX25361) published in 2014
Operator's Manual D100 Series (OMGX25410) published in 2014
Operator's Manual D100 Series (OMGX25658) published in 2014
Operator's Manual D100 Series (OMGX26097) published in 2015
Operator's Manual D100 Series (OMUC11804) published in 2016

Engine

Engine Detail — 724 cc / 44.2 ci Gasoline

Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled vertical-shaft V-Twin
Briggs & Stratton ELS 44
The Deere D160 was rated at 24 HP until 2014. From 2014 on, it was rated at 25 HP.
Displacement	724 cc 44.2 ci
Bore/Stroke	3.12x2.89 inches 79 x 73 mm
Power (gross)	25 hp 18.6 kW
Air cleaner	cartridge with foam pre-cleaner
Starter	electric
Starter volts	12
Oil capacity	2 qts 1.9 L
Sparkplug gap	0.030 inches 0.762 mm
Point gap	0.009 inches 0.229 mm
Intake valve clearance	0.005 inches 0.127 mm
Exhaust valve clearance	0.005 inches 0.127 mm

Transmission

Transmission — Tuff Torq HD K46

Transmission	Tuff Torq HD K46
Type	belt-driven hydrostatic
Gears	infinite forward and reverse
Oil change	sealed unit, owner service is not recommended
Hydrostatic transmission with right-side accelerator and decelerator/reverse foot pedals. Left-side brake pedal. Cruise control is standard equipment.

Dimensions

John Deere D160 Tires
Lawn/turf front	16x6.5-8
Lawn/turf rear	22x9.5-12

Dimensions
Wheelbase	48.9 inches 124 cm
Length	69.25 inches 175 cm
Width	60 inches (mower) 152 cm
Height	45 inches 114 cm
Weight	525 lbs*Weight with mower deck. 238 kg

Attachments

Attachment overview
48" mid-mount mower deck
Snowblower
Blade

48" Mower deck
Type	mid-mount John Deere Edge 48
	3-blade with manual with spring assist lift
Cutting width	48 inches 121 cm
Overall width	60 inches 152 cm
Cut height	1 to 4 inch 2 to 10 cm
Cut positions	13
