John Deere SST15
The John Deere SST15 is a tractor produced by John Deere Lawn Tractors. The listed engine power is Gasoline (gross): 15 hp / 11.2 kW. Transmission: infinite forward and reverse. Operating weight: 615 lbs 278 kg.
Engine Power
Gasoline (gross): 15 hp / 11.2 kW
Fuel & Capacities
2.5 gal
9.5 L
Transmission
infinite forward and reverse
Operating Weight
615 lbs
278 kg
Overview
 | 2001 - 2003
SST SeriesZero-turn mower
SST Series
Zero-turn mower |
|---|
Production | |
|---|---|
Manufacturer | John Deere |
Zero-turn mower | |
Built in Horicon, Wisconsin, USA | |
Original price was $3,749 in 2002 | |
John Deere SST15 Engine | |
|---|---|
15HP Kohler 1-cyl gasoline | |
Fuel tank | 2.5 gal
9.5 L |
Engine details ...  | |
John Deere SST15 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | hydraulic power |
Wet disc brakes | |
Open operator station. | |
Dimensions & Tires | |
|---|---|
Wheelbase | 49.25 inches
125 cm |
Weight | 615 lbs
278 kg |
Front tire | 13x5.0-16 |
Rear tire | 20x10-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery CCA | 160 |
Battery volts | 12 |
References | |
|---|---|
 | |
Lawn and Garden Product Information Handbook published in 2002, by John Deere | |
Lawn and Garden Product Information Handbook published in 2003, by John Deere | |
Lawn and Garden Product Information Handbook published in 2003, by John Deere | |
Lawn and Garden Product Information Handbook published in 2004, by John Deere | |
SST Lawn Tractor published in 2001, by John Deere |
Engine
Engine Detail — Gasoline
Manufacturer | Kohler CVS15S |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Power (gross) | 15 hp
11.2 kW |
Air cleaner | paper and foam elements |
Starter volts | 12 |
Oil capacity | 1.9 qts
1.8 L |
Sparkplug gap | 0.040 inches
1.016 mm |
John Deere SST15 Engine | |
|---|---|
 |
Transmission
Transmission — infinite forward and reverse belt-driven hydrostatic
Manufacturer | Tuff Torq |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
Oil capacity | 6.8 qts
6.4 L |
 | |
Dimensions
John Deere SST15 Tires | |
|---|---|
Lawn/turf front | 13x5.0-16 |
Lawn/turf rear | 20x10-8 |
Dimensions | |
|---|---|
Wheelbase | 49.25 inches
125 cm |
Length | 75 inches
190 cm |
Width | 52.5 inches
133 cm |
Height | 42 inches
106 cm |
Weight | 615 lbs
278 kg |
Photos
John Deere SST15 tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for John Deere Lawn Tractors John Deere SST15 based on its 15 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for John Deere Lawn Tractors John Deere SST15.
Estimated Continuous Field Runtime: 3.2 hrs
Approximately 3.2 hours of continuous field operation at ~75% rated power on a full tank (2.5 gal / 9.5 L).
Estimated 75% Load Fuel Burn~0.8 gal/hr (3 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
John Deere Lawn Tractors John Deere SST15 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for John Deere Lawn Tractors John Deere SST15.
Converted Equivalents:
Horsepower (HP)15 hp
Kilowatts (kW)11.2 kW
Metric Horsepower (PS / CV)15.2 PS
