John Deere X570
The John Deere X570 is a tractor produced by John Deere Lawn Tractors. It is equipped with a 726 cc 44.3 ci engine. The listed engine power is Gasoline (gross): 24 hp / 17.9 kW. Transmission: Kanzaki K72. Operating weight: 606 lbs*Weight of tractor only. 274 kg.
Engine Power
Gasoline (gross): 24 hp / 17.9 kW
Fuel & Capacities
4.4 gal
16.7 L
Transmission
Kanzaki K72
Operating Weight
606 lbs*Weight of tractor only.
274 kg
Overview
 | 2016 -
Select X500 SeriesGarden tractor |
|---|---|
2016 - | |
Select X500 Series | |
Garden tractor | |
Production | |
|---|---|
Manufacturer | John Deere |
Garden tractor | |
Built in Horicon, Wisconsin, USA | |
Original price was $6,299 in 2017 with 54-inch | |
John Deere X570 Engine | |
|---|---|
24HP Kawasaki 726cc 2-cyl gasoline | |
Fuel tank | 4.4 gal
16.7 L |
Engine details ...  | |
John Deere X570 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Differential lock | mechanical rear |
Manual steering | |
Wet disc brakes | |
Open operator station. Canopy and weather cab optional. | |
Tractor hitch | |
|---|---|
Type | sleeve hitch OptOptional |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Mid PTO Type | pulley |
Dimensions & Tires | |
|---|---|
Wheelbase | 51.2 inches
130 cm |
Weight | 606 lbs
274 kg |
Front tire | 15x6.5-8 |
Rear tire | 24x12-12 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | flywheel alternator |
Charging amps | 15 |
Battery CCA | 500 |
Battery volts | 12 |
References | |
|---|---|
 | |
Riding Lawn Tractors published in 2017, by John Deere | |
Riding Lawn Tractors published in 2019, by John Deere | |
Riding Lawn Tractors published in 2016, by John Deere | |
Riding Lawn Tractors published in 2021, by John Deere | |
Riding Lawn Tractors published in 2022, by John Deere | |
Operator's Manual Select Series Tractors (OMM174377) published in 2016 |
Engine
Engine Detail — 726 cc / 44.3 ci Gasoline
Manufacturer | Kawasaki FS730V |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical-shaft V-Twin |
Displacement | 726 cc
44.3 ci |
Bore/Stroke | 3.07x2.99 inches
78 x 76 mm |
Power (gross) | 24 hp
17.9 kW |
Fuel system | carburetor |
Air cleaner | dry with foam precleaner |
Starter volts | 12 |
Oil capacity | 2.2 qts
2.1 L |
Oil change | 100 h |
Transmission
Transmission — Kanzaki K72
Transmission | Kanzaki K72 | ||||
Type | belt-driven hydrostatic | ||||
Gears | infinite forward and reverse | ||||
Oil capacity | 5.6 qts
5.3 L | ||||
Oil type | 86oF [30oC]↓ : JD LV Hy-Gard -10oF [-23oC]↑ : JD Hy-Gard | 86oF [30oC]↓ | : JD LV Hy-Gard | -10oF [-23oC]↑ | : JD Hy-Gard |
86oF [30oC]↓ | : JD LV Hy-Gard | ||||
-10oF [-23oC]↑ | : JD Hy-Gard | ||||
Oil change | 200 h | ||||
 | |||||
86oF [30oC]↓ | : JD LV Hy-Gard |
|---|---|
-10oF [-23oC]↑ | : JD Hy-Gard |
Dimensions
John Deere X570 Tires | |
|---|---|
Lawn/turf front | 15x6.5-8 |
Lawn/turf rear | 24x12-12 |
Dimensions | |
|---|---|
Wheelbase | 51.2 inches
130 cm |
Length | 75 inches
190 cm |
Width | 41 inches
104 cm |
Height | 45 inches
114 cm |
Weight | 606 lbs*Weight of tractor only.
274 kg |
Front axle | Cast-iron |
Attachments
Attachment overview | |
|---|---|
48" mid-mount mower deck | |
54" mid-mount mower deck | |
Snowblower | |
Blade | |
A 30-inch mechanical tiller was available. |
Photos
John Deere X570
John Deere X570
John Deere X570 operator station and controls.
Recommended Implements & Sizing Guide
Engineering recommendations for John Deere Lawn Tractors John Deere X570 based on its 24 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for John Deere Lawn Tractors John Deere X570.
Estimated Continuous Field Runtime: 3.5 hrs
Approximately 3.5 hours of continuous field operation at ~75% rated power on a full tank (4.4 gal / 16.7 L).
Estimated 75% Load Fuel Burn~1.2 gal/hr (4.7 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
John Deere Lawn Tractors John Deere X570 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for John Deere Lawn Tractors John Deere X570.
Converted Equivalents:
Horsepower (HP)24 hp
Kilowatts (kW)17.9 kW
Metric Horsepower (PS / CV)24.3 PS
