Kubota GL29

The Kubota GL29 is a tractor produced by Kubota. It is equipped with a 91.5 ci 1.5 L engine. The rated power output is 28.6 hp 21.3 kW. Transmission: 16 forward and reverse. Operating weight: 2624 lbs 1190 kg.

Overview

	1990 - 1992 GL SeriesCompact Utility tractor
1990 - 1992
GL Series
Compact Utility tractor

Production
Manufacturer	Kubota
Compact Utility tractor

Kubota GL29 Engine
Kubota 1.5L 3-cyl diesel
Fuel tank	9.25 gal 35.0 L
Engine details ...

Kubota GL29 Power
Engine	28.6 hp 21.3 kW
PTO (claimed)	27.1 hp 20.2 kW

Mechanical
Four-wheel drive
Power steering
Mechanical wet disc brakes
Open operator station.

Hydraulics
Pump flow	5.9 gpm 22.3 lpm

Tractor hitch
Rear Type	I
Rear lift	1951 lbs 884 kg

Power Take-off (PTO)
Rear PTO Type	565/800/980/1298 (1.375)

Dimensions & Tires
Wheelbase	68.9 inches 175 cm
Weight	2624 lbs 1190 kg
Front tire	8-16
Rear tire	12.4-24
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

Engine

Engine Detail — 91.5 ci / 1.5 L Diesel

Manufacturer	Kubota D1503
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	91.5 ci 1.5 L
Bore/Stroke	3.268x3.638 inches 83 x 92 mm
Power	28.6 hp 21.3 kW
Rated RPM	2700
Starter	electric
Starter volts	12

Transmission

Transmission options
16-speed gear
16-speed power shift

Transmission — 16 forward and reverse gear

Type	gear
Gears	16 forward and reverse
Four gears (1-4) in low/high ranges plus a creeper/field range shift with shuttle.

Transmission — 16 forward and reverse power shift

Type	power shift
Gears	16 forward and reverse
Eight power shift gears in two ranges with shuttle.

Dimensions

Kubota GL29 Tires
Standard tires (ag)	Front: 8-16. Rear: 12.4-24

Dimensions
Wheelbase	68.9 inches 175 cm
Length	125.2 inches 318 cm
Width	55.9 inches 141 cm
Height	58.1 inches 147 cm
Weight	2624 lbs 1190 kg
Ground clearance	14.2 inches 36 cm
Front tread	44.5 inches 113 cm
Rear tread	42.5 to 60.6 inches 107 to 153 cm

Photos

Kubota GL29 tractor photo
