Kubota KL300
The Kubota KL300 is a tractor produced by Kubota. It is equipped with a 91.5 ci 1.5 L engine. The rated power output is 29.6 hp 22.1 kW. Transmission: 24 forward and 16 reverse. Operating weight: 2910 to 3296 pounds.
Engine Power
29.6 hp
22.1 kW
Fuel & Capacities
10.6 gal
40.1 L
Transmission
24 forward and 16 reverse
Operating Weight
2910 to 3296 pounds
Kubota KL300 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2006 - 2007
KL SeriesCompact Utility tractor |
|---|---|
2006 - 2007 | |
KL Series | |
Compact Utility tractor | |
Production | |
|---|---|
Manufacturer | Kubota |
Compact Utility tractor | |
Kubota KL300 Engine | |
|---|---|
Kubota 1.5L 3-cyl diesel | |
Fuel tank | 10.6 gal
40.1 L |
Engine details ...  | |
Kubota KL300 Power | |
|---|---|
Engine | 29.6 hp
22.1 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Mechanical wet disc brakes | |
Two-post ROPS. Cab optional. |
Tractor hitch | |
|---|---|
Rear Type | I |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540 (1.375) |
Engine RPM | 541@2700 |
763@2700 | |
945@2700 | |
1260@2700 | |
-945@2700 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 68.7 inches
174 cm |
Weight | 2910 to 3296 pounds |
Front tire | 8-16 |
Rear tire | 12.4-26 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Engine
Engine Detail — 91.5 ci / 1.5 L Diesel
Manufacturer | Kubota D1503 |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Displacement | 91.5 ci
1.5 L |
Bore/Stroke | 3.27x3.64 inches
83 x 92 mm |
Power | 29.6 hp
22.1 kW |
Rated RPM | 2700 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
16-speed | |
24-speed |
Transmission — 16 forward and reverse
Gears | 16 forward and reverse |
Four gears (1-4) in two ranges with additional creeper range and shuttle shift. | |
 | |
Transmission | |
Gears | 16 forward and reverse |
Eight gears in two ranges (creeper and high) with shuttle shift. | |
Gears | 24 forward and 16 reverse |
Twelve gears in two ranges (creeper and high) with shuttle shift. Only eight gears available in reverse. 24-speed transmission only on tractors with cabin. | |
Dimensions
Kubota KL300 Tires | |
|---|---|
Standard tires (ag) | Front: 8-16. Rear: 12.4-26 |
Dimensions | |
|---|---|
Wheelbase | 68.7 inches
174 cm |
Length | 125.2 inches
318 cm |
Width | 55.9 inches
141 cm |
Height (ROPS) | 78 inches
198 cm |
Height (cab) | 78.2 inches
198 cm |
ROPS Weight | 2910 lbs
1319 kg |
Cab Weight | 3296 lbs
1495 kg |
Ground clearance | 14.2 inches
36 cm |
Front tread | 44.5 inches
113 cm |
Rear tread | 42.9 to 58.3 inches
108 to 148 cm |
