Kubota M115G
The Kubota M115G is a tractor produced by Kubota. It is equipped with a 373.7 ci 6.1 L engine. The rated power output is 113.5 hp 84.6 kW. Transmission: 32 forward and reverse. Operating weight: 9568 lbs 4340 kg.
Engine Power
113.5 hp
84.6 kW
Fuel & Capacities
50.2 gal
190.0 L
Transmission
32 forward and reverse
Operating Weight
9568 lbs
4340 kg
Kubota M115G Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2014 -
Globe SeriesUtility tractor |
|---|---|
2014 - | |
Globe Series | |
Utility tractor | |
Production | |
|---|---|
Manufacturer | Kubota |
Utility tractor | |
Variants | |
|---|---|
M115G | wheeled |
M115G-PC | half-track crawler |
Kubota M115G Engine | |
|---|---|
Kubota 6.1L 4-cyl diesel | |
Fuel tank | 50.2 gal
190.0 L |
Engine details ...  | |
Kubota M115G Power | |
|---|---|
Engine | 113.5 hp
84.6 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard with air-conditioning. |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and electronic draft control |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Engine RPM | 540@1994 |
1000@2050 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 105.9 inches
268 cm |
Weight | 9568 lbs
4340 kg |
Front tire | 13.6R24 |
Rear tire | 420/85R38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Engine
Engine Detail — 373.7 ci / 6.1 L Diesel
Manufacturer | Kubota V6108-CR-TIE4 |
Configuration | turbocharged diesel, 4-cylinder, liquid-cooled |
Displacement | 373.7 ci
6.1 L |
Bore/Stroke | 4.65x5.51 inches
118 x 140 mm |
Power | 113.5 hp
84.6 kW |
Fuel system | direct injection |
Rated RPM | 2200 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
24-speed power shift | |
32-speed creeper |
Transmission — 24 forward and reverse power shift
Type | power shift |
Gears | 24 forward and reverse |
Clutch | hydraulic wet disc |
Eight power-shift gears in three ranges with shuttle. | |
 | |
Transmission — 32 forward and reverse creeper
Type | creeper |
Gears | 32 forward and reverse |
Optional creeper adds an additional 8-speed range to the standard transmission. | |
 | |
Dimensions
Kubota M115G Tires | |
|---|---|
Standard tires (ag) | Front: 13.6R24. Rear: 420/85R38 |
Dimensions | |
|---|---|
Wheelbase | 105.9 inches
268 cm |
Length | 171.9 inches
436 cm |
Width | 82.7 inches
210 cm |
Height | 111.6 inches
283 cm |
Weight | 9568 lbs
4340 kg |
Ground clearance | 17.1 inches
43 cm |
Front tread | 64.6/68.5 inches
164/173 cm |
Rear tread | 62.2 to 81.1 inches
157 to 205 cm |
Photos
Kubota M115G tractor photo
