Kubota M7500

The Kubota M7500 is a tractor produced by Kubota. It is equipped with a 243 ci 4.0 L engine. The rated power output is 81 hp 60.4 kW. Transmission: 16 forward and 4 reverse. Operating weight: 5082 to 5980 pounds.

Overview

	1979 - 1986 Utility tractor
1979 - 1986
Utility tractor

Production
Manufacturer	Kubota
Utility tractor
Built in Japan

Variants
M7500DT	4WD

Kubota M7500 Engine
Kubota 4.0L 4-cyl diesel
Fuel tank	19.1 gal 72.3 L
Engine details ...

Kubota M7500 Transmission
16-speed
Transmission details ...

Kubota M7500 Power
Engine (gross)	81 hp 60.4 kW
PTO (claimed)	72 hp 53.7 kW
Drawbar (tested)	59.05 hp 44.0 kW
PTO (tested)	72.31 hp 53.9 kW
Performance test details ...

Mechanical
Two- or four-wheel drive
Steering	power
Mechanical wet disc brakes
Two-post ROPS. Optional canopy.

Hydraulics
Type	open center
Valves	1
Total flow	9.25 gpm 35.0 lpm

Tractor hitch
Rear Type	II/I
Rear lift (at ends)	3740 lbs 1696 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540/ground
Engine RPM	540@2016

Dimensions & Tires
2WD Wheelbase	84.84 inches 215 cm
4WD Wheelbase	85.63 inches 217 cm
Weight	5082 to 5980 pounds
Front tire	7.50-16
2WD Rear tire	18.4-28
Full dimensions and tires ...

References
Tractors and Excavators published in 1981, by Kubota
Tractors and Excavators published in 1982, by Kubota
M-Series published in 1985, by Kubota
Diesel M7500 Tractor published in 1981, by Kubota

Engine

Engine Detail — 243 ci / 4.0 L Diesel

Manufacturer	Kubota V4000 A
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	243 ci 4.0 L
Bore/Stroke	4.134x4.528 inches 105 x 115 mm
Power (gross)	81 hp 60.4 kW
Air cleaner	single paper element
Compression	17.0:1
Rated RPM	2400
Starter volts	12

Transmission

Transmission — 16 forward and 4 reverse

Gears	16 forward and 4 reverse
With 18.4-26 rear tires.

Dimensions

Kubota M7500 Tires
2WD Standard tires (ag)	Front: 7.50-16. Rear: 18.4-28
4WD Standard tires (ag)	Front: 11.2-24. Rear: 18.4-28

Dimensions
2WD Wheelbase	84.84 inches 215 cm
4WD Wheelbase	85.63 inches 217 cm
2WD Length	142.91 inches 362 cm
4WD Length	147.83 inches 375 cm
2WD Width	72.83 inches 184 cm
4WD Width	77.36 inches 196 cm
2WD Height (exhaust)	89.96 inches 228 cm
4WD Height (exhaust)	91.14 inches 231 cm
2WD Clearance (front axle)	18.31 inches 46 cm
4WD Clearance (front axle)	14.76 inches 37 cm
2WD Front tread	53.94 to 77.56 inches 137 to 197 cm
4WD Front tread	59.06 inches 150 cm
Rear tread	59.06 to 75.59 inches 150 to 191 cm

Kubota M7500 Weight
2WD Shipping	5082 lbs 2305 kg
4WD Shipping	5610 lbs 2544 kg
4WD Operating	5980 lbs 2712 kg
Ballasted	9510 lbs 4313 kg

Tests

Nebraska Tractor Test 1349
Diesel 16-speed 4WD May 13 - 27, 1980 Link: Nebraska Tractor Test 1349 file
PTO performance
Power at rated engine speed	72.31 hp 53.9 kW
Fuel use	4.3 gal/hour 16.3 l/hour
Power at rated PTO speed	66.54 hp 49.6 kW
Fuel use	3.7 gal/hour 14.0 l/hour
Drawbar performance
Max power	59.05 hp 44.0 kW
Fuel use	4.2 gal/hour 15.9 l/hour
Max pull	7,820 lbs 3547 kg
