Kubota MZ70

The Kubota MZ70 is a tractor produced by Kubota. It is equipped with a 202 ci 3.3 L engine. The rated power output is 69 hp 51.5 kW. Transmission: 24 forward and reverse. Operating weight: 5622 lbs 2550 kg.

Overview

	2006 - 2009 SynerZ SeriesUtility tractor
2006 - 2009
SynerZ Series
Utility tractor

Production
Manufacturer	Kubota
Utility tractor

Kubota MZ70 Engine
Kubota 3.3L 4-cyl diesel
Fuel tank	27.7 gal 104.8 L
Engine details ...

Kubota MZ70 Transmission
24-speed
Transmission details ...

Kubota MZ70 Power
Engine	69 hp 51.5 kW

Mechanical
Four-wheel drive
Power steering
Mechanical wet disc brakes
Cab standard.

Tractor hitch
Rear Type	II/I
Control	position and draft control

Power Take-off (PTO)
Rear PTO Type	540 (1.375)*Three-speed PTO shift with available ground speed or reverse 540
Engine RPM	589@2600
	828@2600
	1170@2600

Dimensions & Tires
Wheelbase	84.7 inches 215 cm
Weight	5622 lbs 2550 kg
Front tire	9.5-22
Rear tire	12.4-36
Full dimensions and tires ...

Engine

Engine Detail — 202 ci / 3.3 L Diesel

Manufacturer	Kubota V3300-T
Configuration	turbocharged diesel, 4-cylinder, liquid-cooled
Displacement	202 ci 3.3 L
Bore/Stroke	3.86x4.33 inches 98 x 110 mm
Power	69 hp 51.5 kW
Rated RPM	2600
Starter type	electric

Transmission

Transmission — 24 forward and reverse

Gears	24 forward and reverse
Clutch	electro-hydraulic wet disc
Eight gears (1-8) in three ranges (creeper, low, and high) with left-hand shuttle shift.

Dimensions

Kubota MZ70 Tires
Standard tires (ag)	Front: 9.5-22. Rear: 12.4-36

Dimensions
Wheelbase	84.7 inches 215 cm
Length	142.7 inches 362 cm
Width	64.6 inches 164 cm
Height (cab)	98.2 inches 249 cm
Weight	5622 lbs 2550 kg
Ground clearance	18.1 inches 45 cm
Front tread	48 to 58.7 inches 121 to 149 cm
Rear tread	48 to 67.7 inches 121 to 171 cm
