Landini 5500
The Landini 5500 is a tractor produced by Landini. It is equipped with a 152.7 ci 2.5 L engine. The listed engine power is Diesel (listed): 50 hp / 37.3 kW. Transmission: 12 forward and 4 reverse. Operating weight: 4476 to 5159 pounds.
Engine Power
Diesel (listed): 50 hp / 37.3 kW
Fuel & Capacities
16.4 gal
62.1 L
Transmission
12 forward and 4 reverse
Operating Weight
4476 to 5159 pounds
Overview
 | 1973 - 1983
Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | Landini |
Utility tractor | |
Landini 5500 Engine | |
|---|---|
Perkins 2.5L 3-cyl diesel | |
Fuel tank | 16.4 gal
62.1 L |
Engine details ...  | |
Landini 5500 Transmission | |
|---|---|
12-speed | |
Transmission details ...  |
Landini 5500 Power | |
|---|---|
Engine | 50 hp
37.3 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Differential lock | mechanical rear |
Steering | mechanical |
hydrostatic power OptOptional | |
Dry disc brakes | |
Four-post ROPS. Cab optional. | |
Hydraulics | |
|---|---|
Pump flow | 7.5 gpm
28.4 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and draft control |
Rear lift | 5072 lbs
2300 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/ground |
1000 (1.375)OptOptional | |
Engine RPM | 540@1944 |
1000@1911 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 81.1 inches
205 cm |
Weight | 4476 to 5159 pounds |
Front tire | 6.50-16 |
Rear tire | 12.4-32 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
5500 four wheel drive published in 1982, by Landini |
Engine
Engine Detail — 152.7 ci / 2.5 L Diesel
Manufacturer | Perkins AD3.152 |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Displacement | 152.7 ci
2.5 L |
Bore/Stroke | 3.60x5.00 inches
91 x 127 mm |
Power | 50 hp
37.3 kW |
Rated RPM | 2250 |
Torque | 131.3 lb-ft
178.0 Nm |
Torque RPM | 1500 |
Transmission
Transmission — 12 forward and 4 reverse
Gears | 12 forward and 4 reverse |
 | |
Dimensions
Landini 5500 Tires | |
|---|---|
Ag front | 6.50-16 |
Ag rear | 12.4-32 |
Ag front | 8.3-24 |
Ag rear | 12.4-32 |
Dimensions | |
|---|---|
Wheelbase | 81.1 inches
205 cm |
Length | 140.2 inches
356 cm |
Height | 53.9 inches
136 cm |
2WD Weight | 4476 lbs
2030 kg |
4WD Weight | 5159 lbs
2340 kg |
Photos
Landini 5500 tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Landini 5500 based on its 50 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm) | Medium Duty | Standard utility farm tillage. |
Rotary Cutter / MowerMowing & Clearing | 6 ft (72 in)1.8 m | Medium Duty | Medium pasture clearing; rear slip-clutch recommended. |
Rotary TillerSeedbed Prep | 66 to 72 in165 - 180 cm | Medium Duty | Standard utility tiller; slip clutch protection required. |
Disc HarrowSecondary Tillage | 7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙 | Medium Duty | Field leveling and clod breaking behind plows. |
Hay BalerHay & Forage | Small Square Baler (14x18")小方捆打捆机 (36x46 cm) | Medium Duty | Classic 2-string baler for horse and small livestock hay. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Landini 5500.
Estimated Continuous Field Runtime: 6.3 hrs
Approximately 6.3 hours of continuous field operation at ~75% rated power on a full tank (16.4 gal / 62.1 L).
Estimated 75% Load Fuel Burn~2.6 gal/hr (9.8 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Landini 5500 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Landini 5500.
Converted Equivalents:
Horsepower (HP)50 hp
Kilowatts (kW)37.3 kW
Metric Horsepower (PS / CV)50.7 PS
