Century 2045

The Century 2045 is a tractor produced by Century. It is equipped with a 134 ci 2.2 L engine. The rated power output is 45 hp 33.6 kW. Transmission: 12 forward and reverse. Operating weight: 3,720 lbs 1687 kg.

Overview

	Kukje built	Kukje built

Kukje built

Production
Distributor	Century
Manufacturer	Kukje
Built in Yangsu-ri, South Korea

Century 2045 Engine
Yanmar 2.2L 4-cyl diesel
Engine details ...

Century 2045 Transmission
12-speed partially synchronized
Transmission details ...

Century 2045 Power
Engine	45 hp 33.6 kW
PTO (claimed)	39.5 hp 29.5 kW

Mechanical
Four-wheel drive
Differential lock	foot pedal
Steering	hydrostatic power
Differential wet disc brakes
ROPS.

Capacity
Fuel	11.2 gal 42.4 L
Hydraulic system	9.25 gal 35.0 L
Front axle	7 qts 6.6 L

Hydraulics
Capacity	9.25 gal 35.0 L
Total flow	8.2 gpm 31.0 lpm

Tractor hitch
Rear Type	I
Rear lift (at ends)	2,580 lbs 1170 kg

Power Take-off (PTO)
Rear PTO	live (two-stage clutch)
Rear PTO Type	540/1000

Dimensions & Tires
Wheelbase	71 inches 180 cm
Weight	3,720 lbs 1687 kg
Front tire	8-18
Rear tire	12.4-28
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
Series 2028 - 2035 - 2045 published by Century
Operator's Manual 2035 and 2045 (948870) published in 2001

Engine

	Kukje built	Kukje built

Kukje built

Engine Detail — 134 ci / 2.2 L Diesel

Manufacturer	Yanmar 4TNE88
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	134 ci 2.2 L
Power	45 hp 33.6 kW
Air cleaner	dry cartridge
Rated RPM	2600
Starter	electric
Starter volts	12
Coolant capacity	9.8 qts 9.3 L
Oil capacity	6 qts 5.7 L

Transmission

	Kukje built	Kukje built

Kukje built

Transmission — 12 forward and reverse partially synchronized

Type	partially synchronized
Gears	12 forward and reverse
Oil capacity	37 qts 35.0 L
Oil type	10oF [-12oC]↑ : JDM J20C 70o↔-40oF [21o↔-40oC] : JDM J20D	10oF [-12oC]↑	: JDM J20C	70o↔-40oF [21o↔-40oC]	: JDM J20D
10oF [-12oC]↑	: JDM J20C
70o↔-40oF [21o↔-40oC]	: JDM J20D
Four gears in three ranges with left-hand shuttle. Synchronized shift (using clutch) between gears. Tractor must be stopped to shift ranges or shuttle.
With 12.4-28 rear tires.

10oF [-12oC]↑	: JDM J20C
70o↔-40oF [21o↔-40oC]	: JDM J20D

Dimensions

	Kukje built	Kukje built

Kukje built

Century 2045 Tires
Ag front	8-18
Ag rear	12.4-28
Lawn/turf front	29/12.50-15
Lawn/turf rear	44/18.00-20
Industrial front	10-16.5
Industrial rear	420/70D-24
Industrial front	12-16.5
Industrial rear	17.5L-24

Dimensions
Wheelbase	71 inches 180 cm
Length	127 inches 322 cm
Width	61 inches 154 cm
Height (ROPS)	88.7 inches 225 cm
Weight	3,720 lbs 1687 kg
Ground clearance	13 inches 33 cm
Front tread	50 to 60 inches 127 to 152 cm
Rear tread	45 to 59 inches 114 to 149 cm

Attachments

	Kukje built	Kukje built

Kukje built

Photos

Century 2045 tractor photo
