Marshall 184
The Marshall 184 is a tractor produced by Marshall. It is equipped with a 51.9 ci 0.9 L engine. The listed engine power is Diesel (listed): 18 hp / 13.4 kW. Transmission: 5 forward and 3 reverse. Operating weight: 1390 lbs 630 kg.
Engine Power
Diesel (listed): 18 hp / 13.4 kW
Fuel & Capacities
1.9 gal
7.2 L
Transmission
5 forward and 3 reverse
Operating Weight
1390 lbs
630 kg
Overview
 | 1992 - ????
Compact Utility tractorFerrari built |
|---|---|
1992 - ???? | |
Compact Utility tractor | |
Ferrari built | |
1992 - ???? | |
|---|---|
Compact Utility tractor | |
Ferrari built |
Production | |
|---|---|
Distributor | Marshall |
Manufacturer | Ferrari |
Compact Utility tractor | |
Marshall 184 Engine | |
|---|---|
Ruggerini 0.9L 2-cyl diesel | |
Fuel tank | 1.9 gal
7.2 L |
Engine details ...  | |
Marshall 184 Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Marshall 184 Power | |
|---|---|
Engine | 18 hp
13.4 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | mechanical rear |
Manual steering | |
Mechanical drum brakes | |
Two-post fixed ROPS. | |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2400 psi
165.5 bar |
Valves | 2 |
Pump flow | 3.2 gpm
12.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Rear lift (at ends) | 1210 lbs
548 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2700 |
1000@2700 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 54.2 inches
137 cm |
Weight | 1390 lbs
630 kg |
Front tire | 6.00-12 |
Rear tire | 7.50-16 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | generator |
Battery volts | 12 |
References | |
|---|---|
 | |
184 & 264 Compact published by Marshall |
Engine
| 1992 - ????
Compact Utility tractorFerrari built |
|---|---|
1992 - ???? | |
Compact Utility tractor | |
Ferrari built | |
1992 - ???? | |
|---|---|
Compact Utility tractor | |
Ferrari built |
Engine Detail — 51.9 ci / 0.9 L Diesel
Manufacturer | Ruggerini RD200 |
Fuel Type | Diesel |
Configuration | 2-cylinder, air-cooled |
Displacement | 51.9 ci
0.9 L |
Power | 18 hp
13.4 kW |
Air cleaner | oil bath |
Rated RPM | 3000 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 3.7 qts
3.5 L |
Transmission
| 1992 - ????
Compact Utility tractorFerrari built |
|---|---|
1992 - ???? | |
Compact Utility tractor | |
Ferrari built | |
1992 - ???? | |
|---|---|
Compact Utility tractor | |
Ferrari built |
Transmission — 5 forward and 3 reverse gear
Type | gear |
Gears | 5 forward and 3 reverse |
Clutch | mechanical dry disc |
Oil capacity | 18.6 qts
17.6 L |
 | |
Dimensions
| 1992 - ????
Compact Utility tractorFerrari built |
|---|---|
1992 - ???? | |
Compact Utility tractor | |
Ferrari built | |
1992 - ???? | |
|---|---|
Compact Utility tractor | |
Ferrari built |
Marshall 184 Tires | |
|---|---|
Ag front | 6.00-12 |
Ag rear | 7.50-16 |
Dimensions | |
|---|---|
Wheelbase | 54.2 inches
137 cm |
Length | 86 inches
218 cm |
Width | 38.6 inches
98 cm |
Height | 45.7 inches
116 cm |
Weight | 1390 lbs
630 kg |
Front tread | 32 to 35 inches
81 to 88 cm |
Rear tread | 31 to 38 inches
78 to 96 cm |
Photos
Marshall 184 tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Marshall 184 based on its 18 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Marshall 184.
Estimated Continuous Field Runtime: 2 hrs
Approximately 2 hours of continuous field operation at ~75% rated power on a full tank (1.9 gal / 7.2 L).
Estimated 75% Load Fuel Burn~0.9 gal/hr (3.5 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Marshall 184 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Marshall 184.
Converted Equivalents:
Horsepower (HP)18 hp
Kilowatts (kW)13.4 kW
Metric Horsepower (PS / CV)18.2 PS
