Marshall 264
The Marshall 264 is a tractor produced by Marshall. It is equipped with a 68.4 ci 1.1 L engine. The rated power output is 25.8 hp 19.2 kW. Transmission: 12 forward and 6 reverse. Operating weight: 1545 lbs 700 kg.
Engine Power
25.8 hp
19.2 kW
Fuel & Capacities
2.6 gal
9.8 L
Transmission
12 forward and 6 reverse
Operating Weight
1545 lbs
700 kg
Marshall 264 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1992 - ????
Compact Utility tractorFerrari built |
|---|---|
1992 - ???? | |
Compact Utility tractor | |
Ferrari built | |
1992 - ???? | |
|---|---|
Compact Utility tractor | |
Ferrari built |
Production | |
|---|---|
Distributor | Marshall |
Manufacturer | Ferrari |
Compact Utility tractor | |
Marshall 264 Engine | |
|---|---|
Lombardini 1.1L 2-cyl diesel | |
Fuel tank | 2.6 gal
9.8 L |
Engine details ...  | |
Marshall 264 Power | |
|---|---|
Engine | 25.8 hp
19.2 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | mechanical rear |
Manual steering | |
Mechanical drum brakes | |
Two-post fixed ROPS. | |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2400 psi
165.5 bar |
Valves | 2 |
Pump flow | 3.2 gpm
12.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Rear lift (at ends) | 1210 lbs
548 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2700 |
1000@2700 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 54.2 inches
137 cm |
Weight | 1545 lbs
700 kg |
Front tire | 6.00-12 |
Rear tire | 8.25-16 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | generator |
Battery volts | 12 |
References | |
|---|---|
 | |
184 & 264 Compact published by Marshall |
Engine
| 1992 - ????
Compact Utility tractorFerrari built |
|---|---|
1992 - ???? | |
Compact Utility tractor | |
Ferrari built | |
1992 - ???? | |
|---|---|
Compact Utility tractor | |
Ferrari built |
Engine Detail — 68.4 ci / 1.1 L Diesel
Manufacturer | Lombardini 9LD561-2 |
Fuel Type | Diesel |
Configuration | 2-cylinder, air-cooled |
Displacement | 68.4 ci
1.1 L |
Bore/Stroke | 3.54x3.46 inches
90 x 88 mm |
Power | 25.8 hp
19.2 kW |
Air cleaner | oil bath |
Compression | 17.5:1 |
Rated RPM | 3000 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 3.7 qts
3.5 L |
Transmission
| 1992 - ????
Compact Utility tractorFerrari built |
|---|---|
1992 - ???? | |
Compact Utility tractor | |
Ferrari built | |
1992 - ???? | |
|---|---|
Compact Utility tractor | |
Ferrari built |
Transmission options | |
|---|---|
6-speed gear | |
12-speed gear |
Transmission — 6 forward and 3 reverse gear
Type | gear |
Gears | 6 forward and 3 reverse |
Clutch | mechanical dry disc |
Oil capacity | 18.6 qts
17.6 L |
 | |
Transmission — 12 forward and 6 reverse gear
Type | gear |
Gears | 12 forward and 6 reverse |
Clutch | mechanical dry disc |
Dimensions
| 1992 - ????
Compact Utility tractorFerrari built |
|---|---|
1992 - ???? | |
Compact Utility tractor | |
Ferrari built | |
1992 - ???? | |
|---|---|
Compact Utility tractor | |
Ferrari built |
Marshall 264 Tires | |
|---|---|
Ag front | 6.00-12 |
Ag rear | 8.25-16 |
Dimensions | |
|---|---|
Wheelbase | 54.2 inches
137 cm |
Length | 86 inches
218 cm |
Width | 39.4 inches
100 cm |
Height | 46.5 inches
118 cm |
Weight | 1545 lbs
700 kg |
Front tread | 32 to 35 inches
81 to 88 cm |
Rear tread | 31 to 38 inches
78 to 96 cm |
Photos
Marshall 264 tractor photo
