Massey Ferguson 112 LT
The Massey Ferguson 112 LT is a tractor produced by Massey Ferguson Lawn Tractors. It is equipped with a 465 cc 28.4 ci engine. The rated power output is 12 hp 8.9 kW. Transmission: 5 forward and 1 reverse. Operating weight: 345 lbs 156 kg.
Engine Power
12 hp
8.9 kW
Fuel & Capacities
2.1 gal
7.9 L
Transmission
5 forward and 1 reverse
Operating Weight
345 lbs
156 kg
Massey Ferguson Lawn Tractors Massey Ferguson 112 LT Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1991 - 1994
100 LTX SeriesLawn tractorIngersoll built |
|---|---|
1991 - 1994 | |
100 LTX Series | |
Lawn tractor | |
Ingersoll built | |
1991 - 1994 | |
|---|---|
100 LTX Series | |
Lawn tractor | |
Ingersoll built |
Production | |
|---|---|
Distributor | Massey Ferguson |
Manufacturer | Ingersoll |
Lawn tractor | |
Massey Ferguson 112 LT Engine | |
|---|---|
12HP Briggs & Stratton 465cc 1-cyl gasoline | |
Fuel tank | 2.1 gal
7.9 L |
Engine details ...  | |
Massey Ferguson 112 LT Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Wheelbase | 42 inches
106 cm |
Weight | 345 lbs
156 kg |
Front tire | 13x6.50-6 |
Rear tire | 18x8.50-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 9 |
Battery volts | 12 |
References | |
|---|---|
 | |
100 Series published in 1990, by Massey Ferguson | |
Lawn and Garden Tractors published in 1991, by Massey Ferguson |
Engine
| 1991 - 1994
100 LTX SeriesLawn tractorIngersoll built |
|---|---|
1991 - 1994 | |
100 LTX Series | |
Lawn tractor | |
Ingersoll built | |
1991 - 1994 | |
|---|---|
100 LTX Series | |
Lawn tractor | |
Ingersoll built |
Engine Detail — 465 cc / 28.4 ci Gasoline
Manufacturer | Briggs & Stratton 28707 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 465 cc
28.4 ci |
Bore/Stroke | 3.44x3.06 inches
87 x 78 mm |
Power (gross) | 12 hp
8.9 kW |
Starter | electric |
Starter volts | 12 |
Oil capacity | 1.125 qts
1.1 L |
Transmission
| 1991 - 1994
100 LTX SeriesLawn tractorIngersoll built |
|---|---|
1991 - 1994 | |
100 LTX Series | |
Lawn tractor | |
Ingersoll built | |
1991 - 1994 | |
|---|---|
100 LTX Series | |
Lawn tractor | |
Ingersoll built |
Transmission — 5 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 5 forward and 1 reverse |
 | |
Dimensions
| 1991 - 1994
100 LTX SeriesLawn tractorIngersoll built |
|---|---|
1991 - 1994 | |
100 LTX Series | |
Lawn tractor | |
Ingersoll built | |
1991 - 1994 | |
|---|---|
100 LTX Series | |
Lawn tractor | |
Ingersoll built |
Massey Ferguson 112 LT Tires | |
|---|---|
Lawn/turf front | 13x6.50-6 |
Lawn/turf rear | 18x8.50-8 |
Dimensions | |
|---|---|
Wheelbase | 42 inches
106 cm |
Length | 60.25 inches
153 cm |
Width | 33 inches
83 cm |
Height | 39 inches
99 cm |
Weight | 345 lbs
156 kg |
Attachments
| 1991 - 1994
100 LTX SeriesLawn tractorIngersoll built |
|---|---|
1991 - 1994 | |
100 LTX Series | |
Lawn tractor | |
Ingersoll built | |
1991 - 1994 | |
|---|---|
100 LTX Series | |
Lawn tractor | |
Ingersoll built |
Attachment overview | |
|---|---|
42" mid-mount mower deck | |
44" mid-mount mower deck | |
Snowblower | |
Blade |
