Massey Ferguson 2411G
The Massey Ferguson 2411G is a tractor produced by Massey Ferguson Lawn Tractors. It is equipped with a 465 cc 28.4 ci engine. The rated power output is 10.5 hp 7.8 kW. Transmission: 5 forward and 1 reverse. Operating weight: 387 lbs*Weight with mower deck. 175 kg.
Engine Power
10.5 hp
7.8 kW
Fuel & Capacities
2 gal
7.6 L
Transmission
5 forward and 1 reverse
Operating Weight
387 lbs*Weight with mower deck.
175 kg
Massey Ferguson Lawn Tractors Massey Ferguson 2411G Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1996 - 2000
2400 SeriesRiding lawn mowerSimplicity built |
|---|---|
1996 - 2000 | |
2400 Series | |
Riding lawn mower | |
Simplicity built | |
1996 - 2000 | |
|---|---|
2400 Series | |
Riding lawn mower | |
Simplicity built |
Production | |
|---|---|
Distributor | Massey Ferguson |
Manufacturer | Simplicity |
Riding lawn mower | |
Built in Port Washington, Wisconsin, USA | |
Variants | |
|---|---|
Coronet 11G | similar Simplicity model |
Massey Ferguson 2411G Engine | |
|---|---|
10.5HP Briggs & Stratton 465cc 1-cyl gasoline | |
Fuel tank | 2 gal
7.6 L |
Engine details ...  | |
Massey Ferguson 2411G Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual |
Open operator station. | |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 43 inches
109 cm |
Weight | 387 lbs
175 kg |
Front tire | 13X5.0-6 |
Rear tire | 16X6.5-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Operator's Manual 2400 Series (1716885) published in 1996 | |
Tractors and Riding Mowers published in 1996, by Massey Ferguson | |
Lawn & Garden Equipment published in 1997, by Massey Ferguson | |
Lawn & Garden Equipment published in 1998, by Massey Ferguson | |
Lawn & Garden Equipment published in 1999, by Massey Ferguson |
Engine
| 1996 - 2000
2400 SeriesRiding lawn mowerSimplicity built |
|---|---|
1996 - 2000 | |
2400 Series | |
Riding lawn mower | |
Simplicity built | |
1996 - 2000 | |
|---|---|
2400 Series | |
Riding lawn mower | |
Simplicity built |
Engine Detail — 465 cc / 28.4 ci Gasoline
Manufacturer | Briggs & Stratton I/C |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 465 cc
28.4 ci |
Bore/Stroke | 3.44x3.06 inches
87 x 78 mm |
Power (gross) | 10.5 hp
7.8 kW |
Rated RPM | 3400 |
Starter | electric |
Starter volts | 12 |
Transmission
| 1996 - 2000
2400 SeriesRiding lawn mowerSimplicity built |
|---|---|
1996 - 2000 | |
2400 Series | |
Riding lawn mower | |
Simplicity built | |
1996 - 2000 | |
|---|---|
2400 Series | |
Riding lawn mower | |
Simplicity built |
Transmission — 5 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 5 forward and 1 reverse |
 | |
Dimensions
| 1996 - 2000
2400 SeriesRiding lawn mowerSimplicity built |
|---|---|
1996 - 2000 | |
2400 Series | |
Riding lawn mower | |
Simplicity built | |
1996 - 2000 | |
|---|---|
2400 Series | |
Riding lawn mower | |
Simplicity built |
Massey Ferguson 2411G Tires | |
|---|---|
Lawn/turf front | 13X5.0-6 |
Lawn/turf rear | 16X6.5-8 |
Dimensions | |
|---|---|
Wheelbase | 43 inches
109 cm |
Length | 61 inches
154 cm |
Width | 33 inches
83 cm |
Height (steering wheel) | 41 inches
104 cm |
Weight | 387 lbs*Weight with mower deck.
175 kg |
Attachments
| 1996 - 2000
2400 SeriesRiding lawn mowerSimplicity built |
|---|---|
1996 - 2000 | |
2400 Series | |
Riding lawn mower | |
Simplicity built | |
1996 - 2000 | |
|---|---|
2400 Series | |
Riding lawn mower | |
Simplicity built |
30" Mower deck | |
|---|---|
Type | mid-mount Massey Ferguson |
1-blade | |
Cutting width | 30 inches
76 cm |
Overall width | 38.5 inches
97 cm |
Cut height | 1 to 3.75 inch
2 to 9 cm |
