Massey Ferguson 2924D
The Massey Ferguson 2924D is a tractor produced by Massey Ferguson Lawn Tractors. It is equipped with a 952 cc 58.1 ci engine. The listed engine power is Diesel (gross): 24.5 hp / 18.3 kW. Transmission: Sundstrand 15U. Operating weight: 690 lbs 312 kg.
Engine Power
Diesel (gross): 24.5 hp / 18.3 kW
Fuel & Capacities
6 gal
22.7 L
Transmission
Sundstrand 15U
Operating Weight
690 lbs
312 kg
Overview
 | 1998 - 2003
2900 SeriesGarden tractorSimplicity built
2900 Series
Garden tractor
Simplicity built |
|---|
Series map: 29232924D2925H23.0hp24.5hp25.0hp
Note: the Massey Ferguson model 2924D is the same as the Simplicity Legacy 24.5. The following data is from the Legacy 24.5 listing. |
Production | |
|---|---|
Distributor | Massey Ferguson |
Manufacturer | Simplicity |
Garden tractor | |
Built in Port Washington, Wisconsin, USA | |
Original price | $10,300 (1998 ) |
$12,000 (2001 ) | |
Massey Ferguson 2924D Engine | |
|---|---|
24.5HP Briggs & Stratton 952cc 3-cyl diesel | |
Fuel tank | 6 gal
22.7 L |
Engine details ...  | |
Massey Ferguson 2924D Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Final drives | spur gear |
Differential lock | mechanical rear |
Power steering | |
Disc brakes | |
Open operator station. Hard-side weather cab optional. Two-post ROPS available. | |
Hydraulics | |
|---|---|
Pressure | 950 psi
65.5 bar |
Pump flow | 3 gpm
11.4 lpm |
Tractor hitch | |
|---|---|
Rear Type | 0 OptOptional |
Rear lift | 450 lbs
204 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent OptOptional |
Clutch | electric |
Rear PTO Type | 540 (1.375) |
2000 (1.0) | |
Front PTO | independent |
Clutch | electro-magnetic |
Dimensions & Tires | |
|---|---|
Wheelbase | 55 inches
139 cm |
Weight | 845 lbs
383 kg |
Front tire | 18x8.5-8 |
Rear tire | 26x12-12 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 40 |
Battery CCA | 500 |
Battery volts | 12 |
References | |
|---|---|
 | |
Lawn & Garden Equipment published in 1998, by Massey Ferguson | |
Lawn & Garden Equipment published in 1999, by Massey Ferguson | |
Lawn & Garden Equipment published in 2000, by Massey Ferguson* | |
Lawn & Garden Equipment published in 2002, by Massey Ferguson | |
Operator's Manual Legacy / 2000 / 2900 Series (1717573) published in 2003 | |
2002 Product Specifications published by Simplicity | |
*Publication contains known errors. |
Engine
Series map: 29232924D2925H23.0hp24.5hp25.0hp
Note: the Massey Ferguson model 2924D is the same as the Simplicity Legacy 24.5. The following data is from the Legacy 24.5 listing. |
Engine Detail — 952 cc / 58.1 ci Diesel
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled horizontal-shaft inline |
Briggs & Stratton DM 950 | |
Displacement | 952 cc
58.1 ci |
Bore/Stroke | 2.87x3.07 inches
73 x 78 mm |
Power (gross) | 24.5 hp
18.3 kW |
Compression | 24:1 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 3.2 qts
3.0 L |
Coolant capacity | 6 qts
5.7 L |
Massey Ferguson 2924D Engine | |
|---|---|
 |
Transmission
Series map: 29232924D2925H23.0hp24.5hp25.0hp
Note: the Massey Ferguson model 2924D is the same as the Simplicity Legacy 24.5. The following data is from the Legacy 24.5 listing. |
Transmission — Sundstrand 15U
Transmission | Sundstrand 15U |
Type | shaft-driven hydrostatic |
Gears | infinite forward and reverse (2-range) |
Oil capacity | 6 qts
5.7 L |
Oil type | ATF F |
Oil change | 400 h |
Sundstrand 15 hydrostatic with Peerless 2600 transaxle. | |
 | |
ATF F |
|---|
Dimensions
Series map: 29232924D2925H23.0hp24.5hp25.0hp
Note: the Massey Ferguson model 2924D is the same as the Simplicity Legacy 24.5. The following data is from the Legacy 24.5 listing. |
Massey Ferguson 2924D Tires | |
|---|---|
Lawn/turf front | 18x8.5-8 |
Lawn/turf rear | 26x12-12 |
Dimensions | |
|---|---|
Wheelbase | 55 inches
139 cm |
Length | 78.75 inches
200 cm |
Width | 44.75 inches
113 cm |
Height (steering wheel) | 51 inches
129 cm |
Height (ROPS) | 76.5 inches
194 cm |
Weight | 845 lbs
383 kg |
Max rear axle | 1800 lbs
816 kg |
Ground clearance | 8 inches
20 cm |
Rear axle | 1.1875 inch diameter
30 mm |
Attachments
Series map: 29232924D2925H23.0hp24.5hp25.0hp
Note: the Massey Ferguson model 2924D is the same as the Simplicity Legacy 24.5. The following data is from the Legacy 24.5 listing. |
Attachment overview | |
|---|---|
48" mid-mount mower deck | |
54" mid-mount mower deck | |
60" mid-mount mower deck | |
Snowblower | |
Blade | |
Front-end loader | |
Backhoe | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
Kwik-Way Backhoe | |
|---|---|
Backhoe type | Kwik-Way Backhoe |
Weight | 690 lbs
312 kg |
Transport height | 85 inches
215 cm |
Bucket width | 9 inches
22 cm |
12 inches
30 cm | |
2-Foot flat digging depth | 78 inches
198 cm |
Reach from pivot | 123 inches
312 cm |
Loading height | 84 inches
213 cm |
Bucket Rotation | 147° |
Swing Arc | 151° |
Photos
Massey Ferguson 2924D
Recommended Implements & Sizing Guide
Engineering recommendations for Massey Ferguson Lawn Tractors Massey Ferguson 2924D based on its 24.5 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Massey Ferguson Lawn Tractors Massey Ferguson 2924D.
Estimated Continuous Field Runtime: 4.7 hrs
Approximately 4.7 hours of continuous field operation at ~75% rated power on a full tank (6 gal / 22.7 L).
Estimated 75% Load Fuel Burn~1.3 gal/hr (4.8 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Massey Ferguson Lawn Tractors Massey Ferguson 2924D Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Massey Ferguson Lawn Tractors Massey Ferguson 2924D.
Converted Equivalents:
Horsepower (HP)24.5 hp
Kilowatts (kW)18.3 kW
Metric Horsepower (PS / CV)24.8 PS
