Massey Ferguson 832
The Massey Ferguson 832 is a tractor produced by Massey Ferguson Lawn Tractors. It is equipped with a 306 cc 18.7 ci engine. The listed engine power is Gasoline (listed): 8 hp / 6.0 kW. Transmission: 3 forward and 1 reverse. Operating weight: 313 lbs 141 kg.
Engine Power
Gasoline (listed): 8 hp / 6.0 kW
Fuel & Capacities
0.75 gal
2.8 L
Transmission
3 forward and 1 reverse
Operating Weight
313 lbs
141 kg
Overview
 | 1974 - 1975
Riding lawn mower |
|---|
Production | |
|---|---|
Manufacturer | Massey Ferguson |
Riding lawn mower | |
Massey Ferguson 832 Engine | |
|---|---|
8HP Tecumseh 306cc 1-cyl gasoline | |
Fuel tank | 0.75 gal
2.8 L |
Engine details ...  | |
Massey Ferguson 832 Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Wheelbase | 36.75 inches
93 cm |
Weight | 313 lbs
141 kg |
Front tire | 11x4.00-5 |
Rear tire | 15x6.00-6 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Complete Farm Machinery Guide published in 1976, by Massey Ferguson |
Engine
Engine Detail — 306 cc / 18.7 ci Gasoline
Manufacturer | Tecumseh |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled |
Displacement | 306 cc
18.7 ci |
Power | 8 hp
6.0 kW |
Starter | manual recoil |
electric OptOptional | |
Starter volts | 12 |
Transmission
Transmission — 3 forward and 1 reverse gear
Type | gear |
Gears | 3 forward and 1 reverse |
 | |
Dimensions
Massey Ferguson 832 Tires | |
|---|---|
Lawn/turf front | 11x4.00-5 |
Lawn/turf rear | 15x6.00-6 |
Dimensions | |
|---|---|
Wheelbase | 36.75 inches
93 cm |
Length | 54 inches
137 cm |
Height (steering wheel) | 38 inches
96 cm |
Weight | 313 lbs
141 kg |
Ground clearance | 3.75 inches
9 cm |
Front tread | 27.5 inches
69 cm |
Rear tread | 26.25 inches
66 cm |
Attachments
32" Mower deck | |
|---|---|
Type | mid-mount Massey Ferguson |
2-blade with manual lift | |
Cutting width | 32 inches
81 cm |
Overall width | 46.5 inches
118 cm |
Cut height | 1.5 to 4 inch
3 to 10 cm |
Cut positions | 7 |
Photos
Massey Ferguson 832 tractor photo
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Massey Ferguson Lawn Tractors Massey Ferguson 832.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Massey Ferguson Lawn Tractors Massey Ferguson 832 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Massey Ferguson Lawn Tractors Massey Ferguson 832.
Converted Equivalents:
Horsepower (HP)8 hp
Kilowatts (kW)6 kW
Metric Horsepower (PS / CV)8.1 PS
