Massey Ferguson ZT 1438

The Massey Ferguson ZT 1438 is a tractor produced by Massey Ferguson Lawn Tractors. The listed engine power is Gasoline (gross): 14 hp / 10.4 kW. Transmission: infinite forward and reverse. Operating weight: 600 lbs (with mower deck) 272 kg.

Engine Power
Gasoline (gross): 14 hp / 10.4 kW
Fuel & Capacities
2 gal 7.6 L
Transmission
infinite forward and reverse
Operating Weight
600 lbs (with mower deck) 272 kg

Overview

Massey Ferguson ZT 1438 tractor photo
1999 - 2001 ZT SeriesZero-turn mowerSimplicity built ZT Series Zero-turn mower Simplicity built
Production
Distributor
Massey Ferguson
Manufacturer
Simplicity
Zero-turn mower
Built in Port Washington, Wisconsin, USA
Massey Ferguson ZT 1438 Engine
14HP Kohler 1-cyl gasoline
Fuel tank
2 gal 7.6 L
Engine details ...
Massey Ferguson ZT 1438 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Steering
hydrostatic differential
Open operator station.
Dimensions & Tires
Wheelbase
43.75 inches 111 cm
Weight
600 lbs 272 kg
Front tire
13x5.0-6
Rear tire
18x9.5-8
Full dimensions and tires ...
Electrical
Ground
negative
Battery volts
12
References
ZT 1438 references literature
Lawn & Garden Equipment published in 1997, by Massey Ferguson
Lawn & Garden Equipment published in 1998, by Massey Ferguson
Lawn & Garden Equipment published in 1999, by Massey Ferguson
Lawn & Garden Equipment published in 2000, by Massey Ferguson*
*Publication contains known errors.

Engine

Engine Detail — Gasoline

Manufacturer
Kohler Command
Fuel Type
Gasoline
Configuration
1-cylinder, air-cooled
Power (gross)
14 hp 10.4 kW
Rated RPM
3400
Starter
electric
Starter volts
12

Transmission

Transmission — infinite forward and reverse hydrostatic

Type
hydrostatic
Gears
infinite forward and reverse

Dimensions

Massey Ferguson ZT 1438 Tires
Lawn/turf front
13x5.0-6
Lawn/turf rear
18x9.5-8
Dimensions
Wheelbase
43.75 inches 111 cm
Length
61.5 inches 156 cm
Width
38 inches 96 cm
Height (steering wheel)
43.5 inches 110 cm
Weight
600 lbs (with mower deck) 272 kg

Attachments

38" Mower deck
Type
mid-mount Massey Ferguson
2-blade
Cutting width
38 inches 96 cm
Overall width
49.5 inches 125 cm
Cut height
1.25 to 4 inch 3 to 10 cm

Photos

Massey Ferguson ZT 1438 tractor photo

Massey Ferguson ZT 1438 tractor photo

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Massey Ferguson Lawn Tractors Massey Ferguson ZT 1438.

Estimated Continuous Field Runtime: 2.7 hrs

Approximately 2.7 hours of continuous field operation at ~75% rated power on a full tank (2 gal / 7.6 L).

Estimated 75% Load Fuel Burn~0.7 gal/hr (2.8 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Massey Ferguson Lawn Tractors Massey Ferguson ZT 1438 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Massey Ferguson Lawn Tractors Massey Ferguson ZT 1438.

Converted Equivalents:

Horsepower (HP)14 hp
Kilowatts (kW)10.4 kW
Metric Horsepower (PS / CV)14.2 PS
