Massey Ferguson 2412H
The Massey Ferguson 2412H is a tractor produced by Massey Ferguson Lawn Tractors. It is equipped with a 398 cc 24.3 ci engine. The listed engine power is Gasoline (listed): 12.5 hp / 9.3 kW. Transmission: infinite forward and reverse. Operating weight: 439 lbs 199 kg.
Engine Power
Gasoline (listed): 12.5 hp / 9.3 kW
Fuel & Capacities
2 gal
7.6 L
Transmission
infinite forward and reverse
Operating Weight
439 lbs
199 kg
Overview
 | 1994 - 1995
2400 SeriesRiding lawn mowerSimplicity built
2400 Series
Riding lawn mower
Simplicity built |
|---|
Production | |
|---|---|
Distributor | Massey Ferguson |
Manufacturer | Simplicity |
Riding lawn mower | |
Variants | |
|---|---|
Coronet 13H | similar Simplicity model |
Massey Ferguson 2412H Engine | |
|---|---|
12.5HP Kohler 398cc 1-cyl gasoline | |
Fuel tank | 2 gal
7.6 L |
Engine details ...  | |
Massey Ferguson 2412H Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Mechanical disc brakes | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Wheelbase | 43 inches
109 cm |
Weight | 439 lbs
199 kg |
Front tire | 13x5.0-6 |
Rear tire | 16x7.5-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery CCA | 340 |
Battery volts | 12 |
References | |
|---|---|
 | |
Tractors and Riding Mowers published in 1994, by Massey Ferguson |
Engine
Engine Detail — 398 cc / 24.3 ci Gasoline
Manufacturer | Kohler |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 398 cc
24.3 ci |
Bore/Stroke | 3.43x2.64 inches
87 x 67 mm |
Power | 12.5 hp
9.3 kW |
Starter | electric |
Starter volts | 12 |
Oil capacity | 1.5 qts
1.4 L |
Transmission
Transmission — infinite forward and reverse belt-driven hydrostatic
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
 | |
Dimensions
Massey Ferguson 2412H Tires | |
|---|---|
Lawn/turf front | 13x5.0-6 |
Lawn/turf rear | 16x7.5-8 |
Dimensions | |
|---|---|
Wheelbase | 43 inches
109 cm |
Length | 61 inches
154 cm |
Height (steering wheel) | 41 inches
104 cm |
Height (hood) | 29 inches
73 cm |
Weight | 439 lbs
199 kg |
Attachments
34" Mower deck | |
|---|---|
Type | mid-mount Massey Ferguson |
2-blade with manual lift | |
Cutting width | 34 inches
86 cm |
Overall width | 45.5 inches
115 cm |
Cut height | 1 to 3.75 inch
2 to 9 cm |
Photos
Massey Ferguson 2412H tractor photo
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Massey Ferguson Lawn Tractors Massey Ferguson 2412H.
Estimated Continuous Field Runtime: 3.1 hrs
Approximately 3.1 hours of continuous field operation at ~75% rated power on a full tank (2 gal / 7.6 L).
Estimated 75% Load Fuel Burn~0.7 gal/hr (2.5 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Massey Ferguson Lawn Tractors Massey Ferguson 2412H Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Massey Ferguson Lawn Tractors Massey Ferguson 2412H.
Converted Equivalents:
Horsepower (HP)12.5 hp
Kilowatts (kW)9.3 kW
Metric Horsepower (PS / CV)12.7 PS
