Massey-Harris 16 Pacer
The Massey-Harris 16 Pacer is a tractor produced by Massey Harris. It is equipped with a 91 ci 1.5 L engine. The rated power output is 18.87 hp 14.1 kW. Transmission: 3 forward and 1 reverse. Operating weight: 1980 lbs 898 kg.
Engine Power
18.87 hp
14.1 kW
Fuel & Capacities
7.5 gal
28.4 L
Transmission
3 forward and 1 reverse
Operating Weight
1980 lbs
898 kg
Massey Harris Massey-Harris 16 Pacer Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1953 - 1955
Row-Crop tractor |
|---|---|
1953 - 1955 | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Massey-Harris |
Row-Crop tractor | |
Massey-Harris 16 Pacer Engine | |
|---|---|
Continental 1.5L 4-cyl gasoline | |
Fuel tank | 7.5 gal
28.4 L |
Engine details ...  | |
Massey-Harris 16 Pacer Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Massey-Harris 16 Pacer Power | |
|---|---|
Plows | 2 *12-inch |
Drawbar (tested) | 17.05 hp
12.7 kW |
Belt (tested) | 18.87 hp
14.1 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Final drives | spur gear |
Manual steering | |
Mechanical contracting band brakes | |
Open operator station. | |
Power Take-off (PTO) | |
|---|---|
Rear PTO | transmission |
live OptOptional | |
Rear PTO Type | 540 |
Engine RPM | 540@1800 |
Dimensions & Tires | |
|---|---|
Wheelbase | 72.25 inches
183 cm |
Weight | 1980 lbs
898 kg |
Front tire | 4.00x15 |
Rear tire | 9-24 |
Full dimensions and tires ...  | |
Belt Pulley | |
|---|---|
Diameter | 5.5 inches
13 cm |
Width | 5.5 inches
13 cm |
RPM | 1990 |
Speed | 3125 ft/min
952.50 meters/min |
References | |
|---|---|
 | |
Power For Your Farm published in 1953, by Massey-Harris | |
Massey-Harris Tractors published in 1954 | |
Massey-Harris Tractors published in 1955 | |
Dyanmic New Tractors published in 1956, by Massey-Harris |
Engine
Engine Detail — 91 ci / 1.5 L Gasoline
Manufacturer | Continental |
Fuel Type | Gasoline |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 91 ci
1.5 L |
Bore/Stroke | 2.875x3.50 inches
73 x 89 mm |
Fuel system | Marvel-Schlebler carburetor |
Air cleaner | oil bath |
Compression | 6.1:1 |
Rated RPM | 1800 |
Idle RPM | 1000-1800 |
Starter type | electric |
Oil capacity | 3.5 qts
3.3 L |
Coolant capacity | 9 qts
8.5 L |
Massey-Harris 16 Pacer Engine | |
|---|---|
 |
Transmission
Transmission — 3 forward and 1 reverse gear
Type | gear |
Gears | 3 forward and 1 reverse |
Clutch | 165.1mm mechanical dry disc |
With 9-24 rear tires. | |
 | |
Dimensions
Massey-Harris 16 Pacer Tires | |
|---|---|
Ag front | 4.00x15 |
Ag rear | 9-24 |
Ag rear | 10-24 |
6-30 | |
Dimensions | |
|---|---|
Wheelbase | 72.25 inches
183 cm |
Length | 103.6 inches
263 cm |
Width | 62.6 inches
159 cm |
Shipping weight | 1980 lbs
898 kg |
Ground clearance | 20.5 inches
52 cm |
Front tread | 44 to 68 inches
111 to 172 cm |
Rear tread | 41 to 69 inches
104 to 175 cm |
Tests
Nebraska Tractor Test 531 | |
|---|---|
Gasoline 3-speed 2WD
November 10 - 15, 1954
Link: Nebraska Tractor Test 531 file | |
Belt power (max) | 18.87 hp
14.1 kW |
Drawbar performance | |
Max power | 17.05 hp
12.7 kW |
Gear 2 used for power test. | |
Max pull | 2118 lbs
960 kg |
Gear 1 used for pull test. | |
Photos
Massey-Harris 16 Pacer tractor photo
