Massey-Harris 333

The Massey-Harris 333 is a tractor produced by Massey Harris. It is equipped with a 208 ci 3.4 L engine. Transmission: 10 forward and 2 reverse. Operating weight: 6000 lbs 2721 kg.

Fuel & Capacities
Diesel
Transmission
10 forward and 2 reverse
Operating Weight
6000 lbs 2721 kg

Overview

Massey-Harris 333 tractor photo
1956 - 1958 Row-Crop tractor
Production
Manufacturer
Massey-Harris
Row-Crop tractor
Built in Racine, Wisconsin, USA
Total built
2,748
Original price was $3,000 in 1958
Massey-Harris 333 Transmission
10-speed gear
Transmission details ...
Massey-Harris 333 Power
Drawbar (claimed)
27 hp 20.1 kW
PTO (claimed)
37 hp 27.6 kW
Drawbar (tested)
37.26 hp 27.8 kW
Belt (tested)
41.89 hp 31.2 kW
Performance test details ...
Mechanical
Two-wheel drive
Steering
manual
power optional
Mechanical expanding shoe brakes
Open operator station.
Tractor hitch
Rear Type
I
Power Take-off (PTO)
Rear PTO
independent
Rear PTO Type
540
Engine RPM
542@1500
Dimensions & Tires
Wheelbase
88.1 inches 223 cm
Weight
6000 lbs 2721 kg
Front tire
6.50-16
Rear tire
11-38
Full dimensions and tires ...
Belt Pulley
Diameter
13.5 inches 34 cm
Width
6.5 inches 16 cm
RPM
876
Speed
3,097 ft/min 943.97 meters/min
References
333 references literature
Dyanmic New Tractors published in 1956, by Massey-Harris

Engine

Engine options
Continental 3.4L 4-cyl gasoline
Continental 3.4L 4-cyl diesel

Engine Detail — 208 ci / 3.4 L Gasoline

Manufacturer
Continental E-208
Fuel Type
Gasoline
Configuration
4-cylinder, liquid-cooled vertical I-head
Displacement
208 ci 3.4 L
Bore/Stroke
3.6875x4.875 inches 94 x 124 mm
Air cleaner
oil bath
Compression
7.15:1
Rated RPM
1500
Starter volts
12
Coolant capacity
17.33 qts 16.4 L

Engine Detail — 208 ci / 3.4 L Diesel

Manufacturer
Continental ED-208
Fuel Type
Diesel
Configuration
4-cylinder, liquid-cooled vertical I-head
Displacement
208 ci 3.4 L
Bore/Stroke
3.6875x4.875 inches 94 x 124 mm
Air cleaner
oil bath
Compression
16:1
Rated RPM
1500
Starter volts
12

Transmission

Transmission — 10 forward and 2 reverse gear

Type
gear
Gears
10 forward and 2 reverse
Five gears (1-5) plus reverse (R) in two ranges (low/high).
333 gear speeds

Dimensions

Massey-Harris 333 Tires
Ag front
6.50-16
Ag rear
11-38
12-38
Dimensions
Wheelbase
88.1 inches 223 cm
Height
84 inches 213 cm
Operating weight
6000 lbs 2721 kg
Ballasted weight
7935 lbs 3599 kg

Tests

Tractor Tests
NTTL 577: diesel 10-speed 2WD
NTTL 603: gasoline 10-speed 2WD
Nebraska Tractor Test 577
Diesel 10-speed 2WD June 8 - 13, 1956 Link: Nebraska Tractor Test 577 file
Belt power (max)
37.15 hp 27.7 kW
Belt fuel use (max)
2.6 gal/hour 9.8 l/hour
Drawbar performance
Max power
33.34 hp 24.9 kW
Gear 3-Hi used for power test.
Max pull
5,262 lbs 2386 kg
Gear 1-Low used for pull test.
Nebraska Tractor Test 603
Gasoline 10-speed 2WD October 25 - November 3, 1956 Link: Nebraska Tractor Test 603 file
Belt power (max)
41.89 hp 31.2 kW
Belt fuel use (max)
3.6 gal/hour 13.6 l/hour
Drawbar performance
Max power
37.26 hp 27.8 kW
Gear 3-Hi used for power test.
Max pull
5,423 lbs 2459 kg
Gear 1-Hi used for pull test.

Photos

Massey-Harris 333 with tricycle front end.

Massey-Harris 333 with tricycle front end.

Massey-Harris 333 with tricycle front end.

Massey-Harris 333 with tricycle front end.

Massey-Harris 333 with tricycle front end.

Massey-Harris 333 with tricycle front end.

Massey-Harris 333 with adjustable wide front end.

Massey-Harris 333 with adjustable wide front end.

Massey-Harris 333 operator station and controls.

Massey-Harris 333 operator station and controls.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Massey Harris Massey-Harris 333.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
