mccormick deering w 6
 | 1940 - 1953
Standard-tread tractor | 1940 - 1953 | Standard-tread tractor |
|---|---|---|---|
1940 - 1953 | |||
Standard-tread tractor | |||
1940 - 1953 | |
|---|---|
Standard-tread tractor |
Engine options | |
|---|---|
International Harvester 4.1L 4-cyl distillate | |
International Harvester 4.1L 4-cyl gasoline |
Engine Detail | |
|---|---|
International Harvester | |
distillate | |
4-cylinder | |
liquid-cooled vertical I-head | |
Displacement | 247.7 ci
4.1 L |
Bore/Stroke | 3.875x5.25 inches
98 x 133 mm |
Air cleaner | oil bath |
Compression | 4.75:1 |
| 4.5:1 (kerosene) |
Rated RPM | 1450 |
Firing order | 1-3-4-2 |
Coolant capacity | 25 qts
23.7 L |
Sparkplug gap | 0.025 inches
0.635 mm |
Point gap | 0.013 inches
0.330 mm |
Intake valve clearance | 0.017 inches (hot)
0.432 mm |
Exhaust valve clearance | 0.017 inches (hot)
0.432 mm |
McCormick-Deering W-6 Engine | |
|---|---|
 |
Engine Detail | |
|---|---|
International Harvester | |
gasoline | |
4-cylinder | |
liquid-cooled vertical I-head | |
Displacement | 247.7 ci
4.1 L |
Bore/Stroke | 3.875x5.25 inches
98 x 133 mm |
Air cleaner | oil bath |
Compression | 5.65:1 |
Rated RPM | 1450 |
Firing order | 1-3-4-2 |
