McCormick Intl MC95

The McCormick Intl MC95 is a tractor produced by Mccormick Intl. It is equipped with a 268.5 ci 4.4 L engine. The rated power output is 90 hp 67.1 kW. Transmission: AutoSpeed. Operating weight: 9610 to 11905 pounds.

Overview

	2003 - 2007 MC SeriesUtility tractor
2003 - 2007
MC Series
Utility tractor

Production
Manufacturer	McCormick Intl
Utility tractor
Built in Doncaster, England

McCormick Intl MC95 Engine
Perkins 4.4L 4-cyl diesel
Engine details ...

McCormick Intl MC95 Power
Engine	90 hp 67.1 kW
PTO (claimed)	74 hp 55.2 kW

Mechanical
Two- or four-wheel drive
Differential lock	mechanical rear
Power steering
Wet disc brakes
ROPS. Cab optional

Capacity
Fuel	52 gal 196.8 L
Hydraulic system	19.8 gal 74.9 L

Hydraulics
Type	pressure flow compensated
Capacity	19.8 gal 74.9 L
Valves	2 to 4
Pump flow	28.8 gpm 109.0 lpm

Tractor hitch
Rear Type	IIN
Rear lift (at ends)	12943 lbs 5870 kg
Rear lift (at 24"/610mm)	8201 lbs 3719 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540/1000 (1.375)
Engine RPM	540@2163
	1000@2200

Dimensions & Tires
Wheelbase	94.5 inches 240 cm
Weight	9610 to 11905 pounds
Front tire	10.0/16
Rear tire	18.4/34
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	95
Battery volts	12

References
MC Series published in 2005, by McCormick
MC Series published in 2008, by McCormick

Engine

Engine Detail — 268.5 ci / 4.4 L Diesel

Manufacturer	Perkins 1104C-44T
Configuration	turbocharged diesel, 4-cylinder, liquid-cooled
Displacement	268.5 ci 4.4 L
Bore/Stroke	4.13x5.00 inches 105 x 127 mm
Emissions	Tier 2
Power	90 hp 67.1 kW
Rated RPM	2200
Torque	286 lb-ft 387.8 Nm
Torque RPM	1400
Starter	electric
Starter volts	12

Transmission

Transmission options
16-speed partial power shift
32-speed partial power shift

Transmission — 16 forward and 12 reverse partial power shift

Type	partial power shift
Gears	16 forward and 12 reverse
Four ranges with four power shift gears in each range.
With 18.4-38 rear tires and 40KPH transmission option.

Transmission — 32 forward and 24 reverse partial power shift

Type	partial power shift
Gears	32 forward and 24 reverse
Four ranges with four power shift gears in each range plus creeper.

Transmission — AutoSpeed

Transmission	AutoSpeed
Type	partial power shift
Gears	16 forward and 12 reverse

Dimensions

McCormick Intl MC95 Tires
Ag front	10.0/16 (2WD)
	13.6/28 (4WD)
Ag rear	18.4/34

Dimensions
Wheelbase	94.5 inches 240 cm
Length	169 inches 429 cm
Width	77 inches 195 cm
Ground clearance	14 inches 35 cm

McCormick Intl MC95 Weight
	9610 lbs (2WD ROPS) 4359 kg
	10198 lbs (4WD ROPS) 4625 kg
	10640 lbs (2WD cab) 4826 kg
	11905 lbs (4WD cab) 5400 kg

Photos

McCormick Intl MC95 tractor photo
