MTD 669 Seven Hundred
The MTD 669 Seven Hundred is a tractor produced by Mtd Lawn Tractors. It is equipped with a 275 cc 16.79 ci engine. The listed engine power is Gasoline (listed): 7 hp / 5.2 kW. Transmission: Peerless 1205. Operating weight: 435 to 467 pounds.
Engine Power
Gasoline (listed): 7 hp / 5.2 kW
Fuel & Capacities
1 gal
3.8 L
Transmission
Peerless 1205
Operating Weight
435 to 467 pounds
Overview
 | 1969 - 1972
Model year 1969-19701971-1972
Garden tractor |
|---|
Production | |
|---|---|
Manufacturer | MTD |
Garden tractor | |
Variants | |
|---|---|
658 | 18" tires, recoil |
659 | recoil start |
668 | 18" tires, electric |
669 | electric start |
MTD 669 Engine | |
|---|---|
7HP Briggs & Stratton 275cc 1-cyl gasoline | |
Fuel tank | 1 gal
3.8 L |
Engine details ...  | |
MTD 669 Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Weight | 435 to 467 pounds |
Front tire | 12.50x4.50 |
Rear tire | 18x6.50 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Battery AH | 32 |
References | |
|---|---|
 | |
Owner's Guide 140-659 and 140-669 (770-2409) published in 1970 | |
Garden Tractor Model No. 149-659 and 149-669 (770-1893) published in 1969 | |
MTD Parts Microfiche (770-9101) published in 1974 | |
The Leading Line '70 published in 1970, by MTD |
Engine
Engine Detail — 275 cc / 16.79 ci Gasoline
Manufacturer | Briggs & Stratton 170404 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled horizontal-shaft |
Displacement | 275 cc
16.79 ci |
Bore/Stroke | 3.00x2.375 inches
76 x 60 mm |
Power | 7 hp
5.2 kW |
Starter | manual recoil |
electric OptOptional | |
Starter volts | 12 |
Transmission
Transmission — Peerless 1205
Transmission | Peerless 1205 |
Type | belt-driven gear |
Gears | 3 forward and 1 reverse |
 | |
Dimensions
MTD 669 Tires | |
|---|---|
Lawn/turf front | 12.50x4.50 |
659 Lawn/turf rear | 18x6.50 |
669 Lawn/turf rear | 18x9.50 |
Dimensions | |
|---|---|
Length | 54 inches
137 cm |
Width | 29 inches
73 cm |
Height | 32 inches
81 cm |
659 Shipping weight | 435 lbs
197 kg |
669 Shipping weight | 467 lbs
211 kg |
Attachments
Attachment overview | |
|---|---|
32" mid-mount mower deck | |
Snowblower | |
Blade | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
32" Mower deck | |
|---|---|
Type | mid-mount MTD |
2-blade with manual lift | |
Cutting width | 32 inches
81 cm |
Overall width | 34 inches
86 cm |
Photos
1969 MTD Seven Hundred (model 149-660)
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Mtd Lawn Tractors MTD 669 Seven Hundred.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Mtd Lawn Tractors MTD 669 Seven Hundred Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Mtd Lawn Tractors MTD 669 Seven Hundred.
Converted Equivalents:
Horsepower (HP)7 hp
Kilowatts (kW)5.2 kW
Metric Horsepower (PS / CV)7.1 PS
