New Holland T9.600

The New Holland T9.600 is a tractor produced by New Holland. It is equipped with a 787 ci 12.9 L engine. The rated power output is 535 hp 398.9 kW. Transmission: Ultra Command. Operating weight: 44046 lbs 19979 kg.

Overview

	2014 - 2023 T9 SeriesFour-wheel Drive (4WD) tractor
2014 - 2023
T9 Series
Four-wheel Drive (4WD) tractor

Production
Manufacturer	New Holland (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA

Variants
T9.600	wheeled
T9.600 SmartTrax	crawler
Steiger 540	similar CaseIH model

New Holland T9.600 Engine
FPT 12.9L 6-cyl diesel
Fuel tank	324 gal 1226.3 L
Exhaust fluid (DEF)	66 gal 249.8 L
Engine details ...

New Holland T9.600 Transmission
17-speed full power shift
Transmission details ...

New Holland T9.600 Power
Engine (gross)	535 hp 398.9 kW
Engine (max)	605 hp 451.1 kW
PTO (claimed)	473 hp 352.7 kW
Drawbar (tested)	441.44 hp 329.2 kW
PTO (tested)	539.81 hp 402.5 kW
Performance test details ...

Mechanical
Four-wheel drive
Steering	hydrostatic power articulated
Wet disc brakes
Trailer brakes	hydraulic OptOptional
Cab standard with air-condioning. Optional Comfort Ride cab suspension. ISOBUS compliant; Intelliview IV; IntelliSteer

Hydraulics
Type	closed center load sensing (CCLS)
Valves	4 to 8
Standard Pump flow	42 gpm 159.0 lpm
High-Flow Pump flow	57 gpm 215.7 lpm
MegaFlow Pump flow	113 gpm 427.7 lpm

Tractor hitch
Rear Type	IVN OptOptional
Control	position control
Rear lift (at 24"/610mm)	19621 lbs 8900 kg
Rear Arms	adjustable link ends
Drawbar	Cat. 4
	Cat. 5 OptOptional

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	1000 (1.75)
Engine RPM	1000@1998 (early)
	1000@1811 (late)

Dimensions & Tires
Wheelbase	154 inches 391 cm
Weight	44046 lbs 19979 kg
Front tire	710/70
Rear tire	710/70
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	200
Batteries	2
Battery CCA	1000
Battery volts	12

References
T9 Series published in 2018, by New Holland

Engine

Engine Detail — 787 ci / 12.9 L Diesel

Manufacturer	FPT Cursor 13 TST
Configuration	two-stage turbocharged inter-cooled and aftercooled diesel, 6-cylinder 24-valve, liquid-cooled
Displacement	787 ci 12.9 L
Bore/Stroke	5.31x5.91 inches 135 x 150 mm
Emissions	Tier IV
Emission control	selective catalytic reduction with diesel oxidation catalyst
Rated Power (gross)	535 hp 398.9 kW
Maximum Power (gross)	605 hp 451.1 kW
Fuel system	electronic direct-injection high pressure common rail
Cooling system	hydraulic fan drive
Rated RPM	2100
Torque	1873 lb-ft 2539.8 Nm
Torque RPM	1400
Starter	electric
Starter volts	24

Transmission

Transmission — Ultra Command

Transmission	Ultra Command
Type	full power shift
Gears	17 forward and 2 reverse

Dimensions

New Holland T9.600 Tires
Ag front	710/70 R42
Ag rear	710/70 R42

Dimensions
Wheelbase	154 inches 391 cm
Length	295 inches 749 cm
Width	120 inches*Minimum 304 cm
Height (cab)	156 inches 396 cm
Shipping weight	44046 lbs 19979 kg
Max weight	56000 lbs 25401 kg
Front axle	Bar: 4.5 by 120 inches 114 by 3048 mm
Bar rear axle	4.5 by 120 inches 114 by 3048 mm

Tests

OCED Tractor Test 2096A
Diesel 16-speed 4WD September 22 - 29, 2014 Link: OCED Tractor Test 2096A file
PTO performance
Max power	539.81 hp 402.5 kW
Fuel use	28.2 gal/hour 106.7 l/hour
Power at rated engine speed	477.75 hp 356.3 kW
Fuel use	26.6 gal/hour 100.7 l/hour
Power at rated PTO speed	535.05 hp 399.0 kW
Fuel use	27.7 gal/hour 104.8 l/hour
Drawbar performance
Max power	441.44 hp 329.2 kW
Fuel use	26.6 gal/hour 100.7 l/hour
Gear 5 used for power test.
Max pull	48640 lbs 22063 kg
Gear 1 used for pull test.

Photos

New Holland T9.600 tractor photo
