Ranch Hand 3402
The Ranch Hand 3402 is a tractor produced by Ranch Hand. The listed engine power is Diesel (listed): 30 hp / 22.4 kW.
Engine Power
Diesel (listed): 30 hp / 22.4 kW
Fuel & Capacities
Diesel
Overview
 | 2004 - 2005
Compact Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | Ranch Hand |
Compact Utility tractor | |
Variants | |
|---|---|
DXL | loader |
Ranch Hand 3402 Engine | |
|---|---|
3-cyl diesel | |
Engine details ...  |
Ranch Hand 3402 Power | |
|---|---|
Engine | 30 hp
22.4 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Two-post folding ROPS. |
Tractor hitch | |
|---|---|
Rear Type | I |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540 (1.375) |
Dimensions & Tires | |
|---|---|
Full dimensions and tires ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Engine
Engine Detail — Diesel
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Power | 30 hp
22.4 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission |
|---|
Dimensions
Ranch Hand 3402 Tires |
|---|
Dimensions |
|---|
Photos
Ranch Hand DXL 3402 compact utility tractor.
Recommended Implements & Sizing Guide
Engineering recommendations for Ranch Hand 3402 based on its 30 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm) | Medium Duty | Standard utility farm tillage. |
Rotary Cutter / MowerMowing & Clearing | 5 ft (60 in)1.5 m | Medium Duty | Pasture maintenance and weeds up to 1.5" diameter. |
Rotary TillerSeedbed Prep | 54 to 60 in135 - 150 cm | Medium Duty | Thorough seedbed preparation in orchards and vegetable plots. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Ranch Hand 3402.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Ranch Hand 3402 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Ranch Hand 3402.
Converted Equivalents:
Horsepower (HP)30 hp
Kilowatts (kW)22.4 kW
Metric Horsepower (PS / CV)30.4 PS
Direct Competitor Comparison
Compare Ranch Hand 3402 against same-era industry alternatives in the same horsepower class.
Current Model
Ranch Hand
Ranch Hand 3402
Engine Power:Diesel (listed): 30 hp / 22.4 kW
★ Baseline Reference
