Roper T432 14
The Roper T432 14 is a tractor produced by Roper Lawn Tractors. It is equipped with a 388 cc 23.70 ci engine. The listed engine power is Gasoline (listed): 14 hp / 10.4 kW. Transmission: Roper. Operating weight: 570 lbs 258 kg.
Engine Power
Gasoline (listed): 14 hp / 10.4 kW
Fuel & Capacities
1.75 gal
6.6 L
Transmission
Roper
Operating Weight
570 lbs
258 kg
Overview
 | 1978 - 1983
Garden tractor |
|---|
Production | |
|---|---|
Manufacturer | Roper |
Garden tractor | |
Built in Orangeburg, South Carolina, USA | |
Roper T432 Engine | |
|---|---|
14HP Tecumseh 388cc 1-cyl gasoline | |
Fuel tank | 1.75 gal
6.6 L |
Engine details ...  | |
Roper T432 Transmission | |
|---|---|
6-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Open operator station. |
Tractor hitch | |
|---|---|
Type | Roper Tri-Hitch |
Dimensions & Tires | |
|---|---|
Weight | 570 lbs
258 kg |
Front tire | 16x6.50x8 |
Rear tire | 23x8.50x12 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Garden Tractors published in 1978, by Roper | |
Tractor and Accessories for 1980 published by Roper | |
Great As All Outdoors published in 1980, by Roper | |
The Season Veterans published in 1981, by Roper | |
Parts and "We Care" Service published in 1986 |
Engine
Engine Detail — 388 cc / 23.70 ci Gasoline
Manufacturer | Tecumseh OH140 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled horizontal-shaft |
Displacement | 388 cc
23.70 ci |
Bore/Stroke | 3.31x2.75 inches
84 x 70 mm |
Power | 14 hp
10.4 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — Roper
Transmission | Roper |
Type | gear |
Gears | 6 forward and 2 reverse |
 | |
Dimensions
Roper T432 Tires | |
|---|---|
Lawn/turf front | 16x6.50x8 |
Lawn/turf rear | 23x8.50x12 |
Dimensions | |
|---|---|
Length | 63 inches
160 cm |
Width | 36.5 inches
92 cm |
Shipping weight | 570 lbs
258 kg |
Attachments
Attachment overview | |
|---|---|
42" mid-mount mower deck | |
Snowblower | |
Blade | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
42" Mower deck | |
|---|---|
Type | mid-mount Roper |
3-blade | |
Cutting width | 42 inches
106 cm |
Photos
Roper T432 14 tractor photo
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Roper Lawn Tractors Roper T432 14.
Estimated Continuous Field Runtime: 2.5 hrs
Approximately 2.5 hours of continuous field operation at ~75% rated power on a full tank (1.8 gal / 6.6 L).
Estimated 75% Load Fuel Burn~0.7 gal/hr (2.8 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Roper Lawn Tractors Roper T432 14 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Roper Lawn Tractors Roper T432 14.
Converted Equivalents:
Horsepower (HP)14 hp
Kilowatts (kW)10.4 kW
Metric Horsepower (PS / CV)14.2 PS
