SAME Centauro 65

The SAME Centauro 65 is a tractor produced by Same. It is equipped with a 230.1 ci 3.8 L engine. The rated power output is 64 hp 47.7 kW. Transmission: 8 forward and 4 reverse. Operating weight: 4839 to 5280 pounds.

Overview

	1972 - 1978 Centauro Series
1972 - 1978
Centauro Series

Production
Manufacturer	SAME

SAME Centauro 65 Engine
SAME 3.8L 4-cyl diesel
Engine details ...

SAME Centauro 65 Transmission
8-speed gear
Transmission details ...

SAME Centauro 65 Power
Engine	64 hp 47.7 kW

Mechanical
Two- or four-wheel drive
Manual steering
Drum brakes
Open operator station.

Power Take-off (PTO)
Rear PTO Type	540

Dimensions & Tires
Wheelbase	84.65 inches 215 cm
Weight	4839 to 5280 pounds
Front tire	6.00-16
Rear tire	14.9-28
Full dimensions and tires ...

Engine

Engine Detail — 230.1 ci / 3.8 L Diesel

Manufacturer	SAME 021-1004V
Fuel Type	Diesel
Configuration	4-cylinder, air-cooled
Displacement	230.1 ci 3.8 L
Bore/Stroke	3.937x4.72 inches 100 x 120 mm
Power	64 hp 47.7 kW
Fuel system	direct injection
Rated RPM	2200
Starter type	electric

Transmission

Transmission — 8 forward and 4 reverse gear

Type	gear
Gears	8 forward and 4 reverse
With 14./13-28 rear tires.

Dimensions

SAME Centauro 65 Tires
2WD Ag front	6.00-16
4WD Ag front	8.3-24
Ag rear	14.9-28

Dimensions
Wheelbase	84.65 inches 215 cm
2WD Length	127.6 inches 324 cm
4WD Length	130.3 inches 330 cm
Width	69.9 inches 177 cm
Height (steering wheel)	59.1 inches 150 cm
Height (hood)	51.6 inches 131 cm
2WD Weight	4839 lbs 2194 kg
4WD Weight	5280 lbs 2395 kg
2WD Ground clearance	19.7 inches 50 cm
4WD Ground clearance	11.8 inches 29 cm
2WD Front tread	51.2 to 82.7 inches 130 to 210 cm
4WD Front tread	55.1 inches 139 cm
Rear tread	51.2 to 78.7 inches 130 to 199 cm

Photos

SAME Centauro 65
