Snapper 331314

The Snapper 331314 is a tractor produced by Snapper Lawn Tractors. It is equipped with a 465 cc 28.4 ci engine. The listed engine power is Gasoline (gross): 13 hp / 9.7 kW. Transmission: 5 forward and 1 reverse. Operating weight: 356 lbs 161 kg.

Overview

	1995 14 SeriesRiding lawn mower 14 Series Riding lawn mower

Production
Manufacturer	Snapper
Riding lawn mower

Snapper 331314 Engine
13HP Briggs & Stratton 465cc 1-cyl gasoline
Fuel tank	1.75 gal 6.6 L
Engine details ...

Snapper 331314 Transmission
5-speed fiction disc
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Drum brakes
Open operator station.

Dimensions & Tires
Wheelbase	46 inches 116 cm
Weight	356 lbs 161 kg
Front tire	4.10x3.50-4
Rear tire	16x7.50-8
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
Operator's Manual Series 14 Rear Engine Riders (2-8387) published in 1994
Rear Engine Riders published in 1995, by Snapper

Engine

Engine Detail — 465 cc / 28.4 ci Gasoline

Manufacturer	Briggs & Stratton
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled vertical-shaft
Displacement	465 cc 28.4 ci
Bore/Stroke	3.44x3.06 inches 87 x 78 mm
Power (gross)	13 hp 9.7 kW
Starter	electric
Starter volts	12
Oil capacity	1.5 qts 1.4 L

Transmission

Transmission — 5 forward and 1 reverse fiction disc

Type	fiction disc
Gears	5 forward and 1 reverse

Dimensions

Snapper 331314 Tires
Lawn/turf front	4.10x3.50-4
Lawn/turf rear	16x7.50-8

Dimensions
Wheelbase	46 inches 116 cm
Length	65 inches 165 cm
Height	39 inches 99 cm
Weight	356 lbs 161 kg

Attachments

33" Mower deck
Type	mid-mount Snapper
	1-blade with manual lift
Cutting width	33 inches 83 cm
Overall width	38 inches 96 cm
Cut height	1.25 to 4 inch 3 to 10 cm
Cut positions	6

Photos

Snapper 331314 tractor photo
