Steiger 2200
The Steiger 2200 is a tractor produced by Steiger. It is equipped with a 425.6 ci 7.0 L engine. The listed engine power is Diesel (listed): 238 hp / 177.5 kW. Transmission: Spicer. Operating weight: 23000 lbs 10432 kg.
Engine Power
Diesel (listed): 238 hp / 177.5 kW
Fuel & Capacities
134 gal
507.2 L
Transmission
Spicer
Operating Weight
23000 lbs
10432 kg
Overview
 | 1963 - 1969
Barn SeriesFour-wheel Drive (4WD) tractor
Barn Series
Four-wheel Drive (4WD) tractor |
|---|
Production | |
|---|---|
Manufacturer | Steiger |
Four-wheel Drive (4WD) tractor | |
Built in Red Lake Falls, Minnesota, USA | |
Steiger 2200 Engine | |
|---|---|
Detroit Diesel 7.0L 6-cyl diesel | |
Engine details ...  |
Steiger 2200 Transmission | |
|---|---|
9-speed | |
Transmission details ...  |
Steiger 2200 Power | |
|---|---|
Engine | 238 hp
177.5 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Final drives | planetary |
Articulated power steering | |
Drum brakes | |
Open operator station. Cab available. | |
Capacity | |
|---|---|
Fuel | 134 gal
507.2 L |
Hydraulic system | 54 gal
204.4 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 54 gal
204.4 L |
Valves | 2 |
Total flow | 40 gpm
151.4 lpm |
Dimensions & Tires | |
|---|---|
Wheelbase | 132 inches
335 cm |
Weight | 23000 lbs
10432 kg |
Front tire | 23.1-26 |
Rear tire | 23.1-26 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Red 4WD Tractors: 1957-2017 by Lee Klancher | |
Red Book 1965 published by Implement & Tractor | |
Red Book 1967 published by Implement & Tractor | |
Red Book 1968 published by Implement & Tractor | |
Red Book 1969 published by Implement & Tractor | |
Ultimate Tractor Power: Articulated Tractors of the World, Volume 2 by Peter Simpson* | |
Steiger Identification Guide: 1969-1998 published by Case IH | |
All-Wheel Power published in 1966, by Steiger | |
All-Wheel Drive Agricultural Tractors published in 1968, by Steiger | |
Extra Heavy-Duty All-Wheel Drive Agricultural Tractors published in 1969, by Steiger | |
*Publication contains known errors. |
Engine
Engine Detail — 425.6 ci / 7.0 L Diesel
Manufacturer | Detroit Diesel 6V71N |
Fuel Type | Diesel |
Configuration | 6-cylinder, liquid-cooled |
Displacement | 425.6 ci
7.0 L |
Bore/Stroke | 4.25x5.00 inches
108 x 127 mm |
Power | 238 hp
177.5 kW |
Air cleaner | dry |
Rated RPM | 2300 |
Transmission
Transmission — Spicer
Transmission | Spicer |
Gears | 9 forward and 2 reverse |
Clutch | 356mm discs |
 | |
Dimensions
Steiger 2200 Tires | |
|---|---|
Ag front | 23.1-26 |
Ag rear | 23.1-26 |
Ag front | 23.1-30 |
Ag rear | 23.1-30 |
Dimensions | |
|---|---|
Wheelbase | 132 inches
335 cm |
Width | 102 inches
259 cm |
Height | 106 inches
269 cm |
Weight | 23000 lbs
10432 kg |
Front tread | 90 inches
228 cm |
Rear tread | 90 inches
228 cm |
Photos
Steiger 2200
Steiger 2200
Steiger 2200
Steiger 2200 tractor.
Recommended Implements & Sizing Guide
Engineering recommendations for Steiger 2200 based on its 238 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 8+ Bottom On-Land Hitch8+ 铧重型机外牵引犁 | Commercial / Field Scale | High horsepower articulated/4WD field plowing. |
Rotary Cutter / MowerMowing & Clearing | 15 to 20 ft Batwing4.6 - 6.1 m 宽幅折叠翼 | Commercial / Field Scale | Large commercial field and roadside mowing operations. |
Rotary TillerSeedbed Prep | 90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机 | Commercial / Field Scale | Deep intensive seedbed preparation for commercial row crops. |
Disc HarrowSecondary Tillage | 24 to 36 ft Heavy Duty Field Disc7.3 - 11.0 m 超宽重型整地耙 | Commercial / Field Scale | Broad-acre grain tillage for high-drawbar tractors. |
Hay BalerHay & Forage | Large Square Baler (3x4 or 4x4)大方捆商用打捆机 (1.2x1.2 m) | Commercial / Field Scale | High-capacity commercial forage harvesting (1000 RPM PTO). |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Steiger 2200.
Estimated Continuous Field Runtime: 10.8 hrs
Approximately 10.8 hours of continuous field operation at ~75% rated power on a full tank (134 gal / 507.2 L).
Estimated 75% Load Fuel Burn~12.4 gal/hr (46.8 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Steiger 2200 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Steiger 2200.
Converted Equivalents:
Horsepower (HP)238 hp
Kilowatts (kW)177.5 kW
Metric Horsepower (PS / CV)241.3 PS
Direct Competitor Comparison
Compare Steiger 2200 against same-era industry alternatives in the same horsepower class.
Current Model
Steiger
Steiger 2200
Engine Power:Diesel (listed): 238 hp / 177.5 kW
★ Baseline Reference
