Steiger Super Wildcat II ST-200

The Steiger Super Wildcat II ST-200 is a tractor produced by Steiger. It is equipped with a 636 ci 10.4 L engine. The listed engine power is Diesel (listed): 200 hp / 149.1 kW; Diesel (listed): 200 hp / 149.1 kW. Transmission: Dana-Spicer ST-1010.

Overview

	1974 - 1975 II SeriesFour-wheel Drive (4WD) tractor II Series Four-wheel Drive (4WD) tractor

Production
Manufacturer	Steiger
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Original price was $34,500 in 1975

Variants
RC-200	row-crop axles

Steiger Super Wildcat II ST-200 Transmission
10-speed
Transmission details ...

Steiger Super Wildcat II ST-200 Power
Engine	200 hp 149.1 kW

Mechanical
Four-wheel drive
Final drives	outboard planetary
Articulated power steering
Hydraulic disc brakes
Cab standard with optional heat and air-conditioning.

Hydraulics
Type	open center
Valves	3
Pump flow	25 gpm 94.6 lpm
Total flow	43 gpm 162.8 lpm
Steering flow	17 gpm 64.3 lpm

Tractor hitch
Rear Type	III OptOptional

Dimensions & Tires
Wheelbase	118 inches 299 cm
Front tire	23.1-30
Rear tire	23.1-30
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	55
Battery volts	12

References
4-Wheel Drive Agri-Power published in 1974, by Steiger

Engine

Engine options
Caterpillar 9.4L 8-cyl diesel
Caterpillar 10.4L 8-cyl diesel

Engine Detail — 573 ci / 9.4 L Diesel

Manufacturer	Caterpillar 3150
Fuel Type	Diesel
Configuration	8-cylinder, liquid-cooled V-8
Displacement	573 ci 9.4 L
Bore/Stroke	4.50x4.50 inches 114 x 114 mm
Power	200 hp 149.1 kW
Rated RPM	3000
Torque	379 lb-ft 513.9 Nm
Torque RPM	1400
Starter volts	12
Coolant capacity	40 qts 37.9 L

Engine Detail — 636 ci / 10.4 L Diesel

Manufacturer	Caterpillar 3208
Fuel Type	Diesel
Configuration	8-cylinder, liquid-cooled
Displacement	636 ci 10.4 L
Bore/Stroke	4.50x5.00 inches 114 x 127 mm
Power	200 hp 149.1 kW

Transmission

Transmission — Dana-Spicer ST-1010

Transmission	Dana-Spicer ST-1010
Gears	10 forward and 2 reverse
Clutch	256mm discs
With 23.1-30 tires.

Dimensions

Steiger Super Wildcat II ST-200 Tires
Ag front	23.1-30
Ag rear	23.1-30
Ag front	18.4-34
	20.8-34
	23.1-34
	24.5-32
	30.5-32
	28.1-26
Ag rear	18.4-34
	20.8-34
	23.1-34
	24.5-32
	30.5-32
	28.1-26

Dimensions
Wheelbase	118 inches 299 cm
Length	228 inches 579 cm
Width	96 inches*Width with 23.1-30 rear tires. 243 cm
Height (cab)	125 inches 317 cm
Front tread	60 to 90 inches 152 to 228 cm (RC-200)
Rear tread	60 to 90 inches 152 to 228 cm (RC-200)
