Steiger 800 Tiger

The Steiger 800 Tiger is a tractor produced by Steiger. It is equipped with a 903 ci 14.8 L engine. The listed engine power is Diesel (listed): 300 hp / 223.7 kW. Transmission: Spicer.

Engine Power

Diesel (listed): 300 hp / 223.7 kW

Fuel & Capacities

Diesel

Transmission

Spicer

Overview

	1969 Barn SeriesFour-wheel Drive (4WD) tractor Barn Series Four-wheel Drive (4WD) tractor

Production
Manufacturer	Steiger
Four-wheel Drive (4WD) tractor
Built in Red Lake Falls, Minnesota, USA

Steiger 800 Tiger Engine
Cummins 14.8L 8-cyl diesel
Engine details ...

Steiger 800 Tiger Transmission
10-speed
Transmission details ...

Steiger 800 Tiger Power
Engine	300 hp 223.7 kW

Mechanical
Four-wheel drive
Articulated power steering

Dimensions & Tires
Full dimensions and tires ...

References

Steiger Identification Guide: 1969-1998 published by Case IH

Engine

Engine Detail — 903 ci / 14.8 L Diesel

Manufacturer	Cummins V903
Fuel Type	Diesel
Configuration	8-cylinder, liquid-cooled
Displacement	903 ci 14.8 L
Bore/Stroke	5.50x4.75 inches 140 x 121 mm
Power	300 hp 223.7 kW

Transmission

Transmission — Spicer

Transmission	Spicer
Gears	10 forward and 2 reverse

Dimensions

Steiger 800 Tiger Tires

Dimensions

Recommended Implements & Sizing Guide

Engineering recommendations for Steiger 800 Tiger based on its 300 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	8+ Bottom On-Land Hitch8+ 铧重型机外牵引犁	Commercial / Field Scale	High horsepower articulated/4WD field plowing.
Rotary Cutter / MowerMowing & Clearing	15 to 20 ft Batwing4.6 - 6.1 m 宽幅折叠翼	Commercial / Field Scale	Large commercial field and roadside mowing operations.
Rotary TillerSeedbed Prep	90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机	Commercial / Field Scale	Deep intensive seedbed preparation for commercial row crops.
Disc HarrowSecondary Tillage	24 to 36 ft Heavy Duty Field Disc7.3 - 11.0 m 超宽重型整地耙	Commercial / Field Scale	Broad-acre grain tillage for high-drawbar tractors.
Hay BalerHay & Forage	Large Square Baler (3x4 or 4x4)大方捆商用打捆机 (1.2x1.2 m)	Commercial / Field Scale	High-capacity commercial forage harvesting (1000 RPM PTO).

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Steiger 800 Tiger.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours
