Ursus 1934
The Ursus 1934 is a tractor produced by Ursus. It is equipped with a 445.4 ci 7.3 L engine. The rated power output is 187.7 hp 140.0 kW. Transmission: 16 forward and 8 reverse. Operating weight: 13625 lbs 6180 kg.
Engine Power
187.7 hp
140.0 kW
Fuel & Capacities
93.8 gal
355.0 L
Transmission
16 forward and 8 reverse
Operating Weight
13625 lbs
6180 kg
Ursus 1934 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2001 - 2009
30 Series |
|---|---|
2001 - 2009 | |
30 Series | |
Production | |
|---|---|
Manufacturer | Ursus |
Built in Warsaw, Poland | |
Ursus 1934 Engine | |
|---|---|
Zetor 7.3L 6-cyl diesel | |
Engine details ...  |
Ursus 1934 Transmission | |
|---|---|
16-speed two-speed power shift | |
Transmission details ...  |
Ursus 1934 Power | |
|---|---|
Engine | 187.7 hp
140.0 kW |
PTO (claimed) | 166.3 hp
124.0 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | electro-hydraulic front and rear |
Power steering | |
Wet disc brakes | |
Cab standard with heater. Air-conditioning optional. | |
Capacity | |
|---|---|
Fuel | 93.8 gal
355.0 L |
Hydraulic system | 14.5 gal
54.9 L |
Hydraulics | |
|---|---|
Capacity | 14.5 gal
54.9 L |
Pump flow | 14.5 gpm
54.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Control | position and draft control |
Rear lift | 15873 lbs
7199 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | hydraulic |
Rear PTO Type | 540/1000 (1.375) |
1000 (1.75) | |
Engine RPM | 540@1890 |
1000@1920 | |
Front PTO | 1000 OptOptional |
Dimensions & Tires | |
|---|---|
Wheelbase | 106.5 inches
270 cm |
Weight | 13625 lbs
6180 kg |
Front tire | 16.9R28 |
Rear tire | 20.8R38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Charging amps | 55 |
Charging volts | 14 |
Batteries | 2 |
Battery volts | 12 |
Battery AH | 172 |
Engine
Engine Detail — 445.4 ci / 7.3 L Diesel
Manufacturer | Zetor Z 8604.020 |
Configuration | turbocharged intercooled diesel, 6-cylinder, liquid-cooled |
Displacement | 445.4 ci
7.3 L |
Bore/Stroke | 4.33x5.04 inches
110 x 128 mm |
Power | 187.7 hp
140.0 kW |
Fuel system | direct injection |
Air cleaner | dual dry element |
Compression | 15.6:1 |
Rated RPM | 220 |
Torque | 532.5 lb-ft
722.1 Nm |
Torque RPM | 1530 |
Starter | electric |
Starter volts | 24 |
Starter power | 9 hp
6.7 kW |
Oil capacity | 20.1 qts
19.0 L |
Coolant capacity | 30.6 qts
29.0 L |
Transmission
Transmission — 16 forward and 8 reverse two-speed power shift
Type | two-speed power shift |
Gears | 16 forward and 8 reverse |
Clutch | 380mm hydraulic dry disc |
Oil capacity | 58.1 qts
55.0 L |
Four gears (1-4) in two ranges (I/II) plus reverse range (R) with two-speed power shift. | |
 | |
Dimensions
Ursus 1934 Tires | |
|---|---|
Standard tires (ag) | Front: 16.9R28. Rear: 20.8R38 |
Dimensions | |
|---|---|
Wheelbase | 106.5 inches
270 cm |
Length | 177.2 inches
450 cm |
Width | 95.9 inches
243 cm |
Height (cab) | 118.9 inches
302 cm |
Height (exhaust) | 119.7 inches
304 cm |
Weight | 13625 lbs
6180 kg |
Ballasted weight | 17968 lbs
8150 kg |
Ground clearance | 19.7 inches
50 cm |
Front tread | 66.5/70.5/74.4 inches
168/179/188 cm |
Rear tread | 70.9 inches
180 cm |
