White 185
The White 185 is a tractor produced by White. It is equipped with a 504.5 ci 8.3 L engine. The rated power output is 187.55 hp 139.9 kW. Transmission: 3x6 Over/Under. Operating weight: 13600 to 17150 pounds.
Engine Power
187.55 hp
139.9 kW
Fuel & Capacities
74 gal
280.1 L
Transmission
3x6 Over/Under
Operating Weight
13600 to 17150 pounds
White 185 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1986 - 1989
100 SeriesRow-Crop tractor |
|---|---|
1986 - 1989 | |
100 Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | White |
Row-Crop tractor | |
Built in Coldwater, Ohio, USA | |
Original price was $61,000 in 1989 | |
White 185 Engine | |
|---|---|
CDC-Cummins 8.3L 6-cyl diesel | |
Engine details ...  |
White 185 Transmission | |
|---|---|
18-speed partial powershift | |
Transmission details ...  |
White 185 Power | |
|---|---|
PTO (claimed) | 185 hp
138.0 kW |
Drawbar (tested) | 163.56 hp
122.0 kW |
PTO (tested) | 187.55 hp
139.9 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Final drives | planetary |
Differential lock | hydraulic rear |
Power steering | |
Independent hydraulic wet disc brakes | |
Cab standard with air-conditioning. Optional radio, cassette, and 8-track. | |
Capacity | |
|---|---|
Fuel | 74 gal
280.1 L |
Hydraulic system | 23 gal
87.1 L |
Hydraulics | |
|---|---|
Type | closed center pressure compensated |
Capacity | 23 gal
87.1 L |
Pressure | 2250 psi
155.1 bar |
Valves | 2 or 3 |
Pump flow | 22 gpm
83.3 lpm |
Tractor hitch | |
|---|---|
Rear Type | III/II |
Control | position and draft control |
Rear lift | 7035 lbs
3191 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | hydraulic wet disc |
Rear PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 112 inches
284 cm |
4WD Wheelbase | 90 inches
228 cm |
Weight | 13600 to 17150 pounds |
Front tire | 14L-16 |
Rear tire | 20.8R-38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 62 |
Batteries | 2 |
Battery volts | 12 |
References | |
|---|---|
 | |
Field Boss 185 published in 1987, by White | |
White 185 published in 1987 |
Engine
Engine Detail — 504.5 ci / 8.3 L Diesel
Manufacturer | CDC-Cummins |
Configuration | turbocharged diesel, 6-cylinder, liquid-cooled inline |
Displacement | 504.5 ci
8.3 L |
Bore/Stroke | 4.49x5.32 inches
114 x 135 mm |
Fuel system | direct injection |
Air cleaner | dual paper elements |
Compression | 16.5:1 |
Rated RPM | 2200 |
Starter volts | 12 |
Oil capacity | 23.5 qts
22.2 L |
Coolant capacity | 26.6 qts
25.2 L |
Transmission
Transmission — 3x6 Over/Under
Transmission | 3x6 Over/Under |
Type | partial powershift |
Gears | 18 forward and 6 reverse |
Clutch | 355.6mm dry discs |
Six forward and two reverse gears with an over and under powershift for each gear. | |
 | |
Dimensions
White 185 Tires | |
|---|---|
Ag front | 14L-16 |
Ag rear | 20.8R-38 |
Dimensions | |
|---|---|
2WD Wheelbase | 112 inches
284 cm |
4WD Wheelbase | 90 inches
228 cm |
Length | 168 inches
426 cm |
Width | 98 inches
248 cm |
115 inches (long axle)
292 cm | |
2WD Height | 120 inches
304 cm |
4WD Height | 122 inches
309 cm |
2WD Clearance (front axle) | 23 inches
58 cm |
4WD Clearance (front axle) | 17 inches
43 cm |
Clearance (rear axle) | 28.7 inches
72 cm |
Clearance (drawbar) | 16.7 inches
42 cm |
Bar rear axle | 3.75 by 96 inches
95 by 2438 mm |
Bar rear axle | 3.75 by 115 inches
95 by 2921 mm |
2WD Front tread | 60 to 80 inches
152 to 203 cm |
4WD Front tread | 61 to 87 inches
154 to 220 cm |
Rear tread | 65 to 106 inches
165 to 269 cm |
Rear tread | 65 to 126 inches
165 to 320 cm |
White 185 Weight | |
|---|---|
2WD Shipping | 13600 lbs
6168 kg |
4WD Shipping | 15100 lbs
6849 kg |
4WD Operating | 17150 lbs
7779 kg |
Ballasted | 18770 lbs
8514 kg |
Tests
Nebraska Tractor Test 1608 | |
|---|---|
Diesel 18-speed 4WD
April 5 - 18, 1988
Link: Nebraska Tractor Test 1608 file | |
PTO performance | |
Power at rated engine speed | 187.55 hp
139.9 kW |
Fuel use | 10.9 gal/hour
41.3 l/hour |
Power at rated PTO speed | 192.38 hp
143.5 kW |
Fuel use | 11.1 gal/hour
42.0 l/hour |
Drawbar performance | |
Max power | 163.56 hp
122.0 kW |
Fuel use | 10.8 gal/hour
40.9 l/hour |
Gear 4-direct used for power test. | |
Max pull | 18,318 lbs
8309 kg |
Gear 2-over used for pull test. | |
Photos
White 185 tractor photo
