White Workhorse 195

The White Workhorse 195 is a tractor produced by White. It is equipped with a 504.5 ci 8.3 L engine. The rated power output is 187.55 hp 139.9 kW. Transmission: 3x6 Over/Under. Operating weight: 15545 lbs 7051 kg.

Overview

	1990 - 1992 Workhorse SeriesRow-Crop tractor
1990 - 1992
Workhorse Series
Row-Crop tractor

Production
Manufacturer	White
Row-Crop tractor
Original price was $66,000 in 1992

White 195 Engine
CDC-Cummins 8.3L 6-cyl diesel
Fuel tank	74 gal 280.1 L
Engine details ...

White 195 Transmission
18-speed partial power shift
Transmission details ...

White 195 Power
Drawbar (tested)	163.56 hp 122.0 kW
PTO (tested)	187.55 hp 139.9 kW
Performance test details ...

Mechanical
Four-wheel drive
Differential lock	hydraulic rear
Power steering
Differential hydraulic wet disc brakes
Cab standard with air-conditioning.

Hydraulics
Type	closed center
Pressure	2500 psi 172.4 bar
Rear valves	2 or 3
Pump flow	22 gpm 83.3 lpm

Tractor hitch
Rear Type	III
Control	lower-link draft sensing
Rear lift	8500 lbs 3855 kg
	9900 lbsOptOptional 4490 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	1000

Dimensions & Tires
4WD Wheelbase	102 inches 259 cm
Weight	15545 lbs 7051 kg
Full dimensions and tires ...

Electrical
Ground	negative

References
Workhorse Tractors published in 1990, by White

Engine

Engine Detail — 504.5 ci / 8.3 L Diesel

Manufacturer	CDC-Cummins
Configuration	turbocharged aftercooled diesel, 6-cylinder, liquid-cooled
Displacement	504.5 ci 8.3 L
Bore/Stroke	4.49x5.32 inches 114 x 135 mm
Air cleaner	dual paper elements
Compression	16.5:1
Rated RPM	2200
Starter volts	12

Transmission

Transmission — 3x6 Over/Under

Transmission	3x6 Over/Under
Type	partial power shift
Gears	18 forward and 6 reverse
Six forward and two reverse gears with an over and under powershift for each gear.

Dimensions

White 195 Tires

Dimensions
4WD Wheelbase	102 inches 259 cm
2WD Length	180 inches 457 cm
4WD Length	173 inches 439 cm
Operating weight	15545 lbs 7051 kg
Ballasted weight	18770 lbs 8514 kg
2WD Front tread	60 to 80 inches 152 to 203 cm
4WD Front tread	63.1 to 80.8 inches 160 to 205 cm
Rear tread	60 to 96 inches 152 to 243 cm

Tests

Nebraska Tractor Test 1608
Diesel 18-speed 4WD April 5 - 18, 1988 Link: Nebraska Tractor Test 1608 file
PTO performance
Power at rated engine speed	187.55 hp 139.9 kW
Fuel use	10.9 gal/hour 41.3 l/hour
Power at rated PTO speed	192.38 hp 143.5 kW
Fuel use	11.1 gal/hour 42.0 l/hour
Drawbar performance
Max power	163.56 hp 122.0 kW
Fuel use	10.8 gal/hour 40.9 l/hour
Gear 4-direct used for power test.
