White FR-200 Turf Boss

The White FR-200 Turf Boss is a tractor produced by White Lawn Tractors. It is equipped with a 569 cc 34.75 ci engine. The listed engine power is Gasoline (listed): 20 hp / 14.9 kW. Transmission: infinite forward and reverse. Operating weight: 735 lbs 333 kg.

Engine Power

Gasoline (listed): 20 hp / 14.9 kW

Fuel & Capacities

Gasoline

Transmission

infinite forward and reverse

Operating Weight

735 lbs 333 kg

Overview

	1996 - 1997 FR SeriesFront-mount mower FR Series Front-mount mower

Production
Manufacturer	White (a part of MTD)
Front-mount mower
Original price was $6,400 in 1997

White FR-200 Engine
20HP Briggs & Stratton 569cc 2-cyl gasoline
Engine details ...

White FR-200 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Power steering
Open operator station.

Power Take-off (PTO)
Front PTO	independent
Clutch	electro-magnetic

Dimensions & Tires
Weight	735 lbs 333 kg
Front tire	18x9.50-8
Rear tire	13x5.00-6
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Battery volts	12

References

Lawn Tractors - Garden Tractors - FR Series published in 1996, by White
Lawn Tractors - Garden Tractors - Zero-Turn Mowers published in 1997, by White

Engine

Engine Detail — 569 cc / 34.75 ci Gasoline

Manufacturer	Briggs & Stratton 350447
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled horizontal-shaft V-twin
Displacement	569 cc 34.75 ci
Bore/Stroke	2.83x2.75 inches 72 x 70 mm
Power	20 hp 14.9 kW
Air cleaner	dry
Starter	electric
Starter volts	12

Transmission

Transmission — infinite forward and reverse hydrostatic

Type	hydrostatic
Gears	infinite forward and reverse

Dimensions

White FR-200 Tires
Lawn/turf front	18x9.50-8
Lawn/turf rear	13x5.00-6

Dimensions
Shipping weight	735 lbs 333 kg

Attachments

Attachment overview
52" front-mount mower deck
62" front-mount mower deck
Snowblower
Blade

Photos

White FR-200 Turf Boss tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for White Lawn Tractors White FR-200 Turf Boss based on its 20 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	4 ft (48 in)1.2 m	Light Duty	Pasture clipping and light brush under 1" diameter.
Rotary TillerSeedbed Prep	42 to 48 in105 - 120 cm	Light Duty	Covers compact tractor tire width.
Disc HarrowSecondary Tillage	5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)	Light Duty	Small acreage soil break-up and secondary aeration.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for White Lawn Tractors White FR-200 Turf Boss.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

White Lawn Tractors White FR-200 Turf Boss Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for White Lawn Tractors White FR-200 Turf Boss.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)20 hp

Kilowatts (kW)14.9 kW

Metric Horsepower (PS / CV)20.3 PS
