Wingin XLT-180
The Wingin XLT-180 is a tractor produced by Wingin. The listed engine power is Diesel (listed): 18 hp / 13.4 kW. Operating weight: 3,220 lbs 1460 kg.
Engine Power
Diesel (listed): 18 hp / 13.4 kW
Fuel & Capacities
Diesel
Operating Weight
3,220 lbs
1460 kg
Overview
![]() | Jinma built | Jinma built |
|---|
Jinma built |
|---|
Production | |
|---|---|
Distributor | Wingin |
Manufacturer | Jinma |
Built in China | |
Wingin XLT-180 Engine | |
|---|---|
2-cyl diesel | |
Engine details ... |
Wingin XLT-180 Power | |
|---|---|
Engine | 18 hp
13.4 kW |
Mechanical | |
|---|---|
Two-wheel drive |
Dimensions & Tires | |
|---|---|
Wheelbase | 56.7 inches
144 cm |
Weight | 3,220 lbs
1460 kg |
Full dimensions and tires ... | |
Engine
![]() | Jinma built | Jinma built |
|---|
Jinma built |
|---|
Engine Detail — Diesel
Manufacturer | TY295 |
Fuel Type | Diesel |
Configuration | 2-cylinder, liquid-cooled |
Power | 18 hp
13.4 kW |
Rated RPM | 2200 |
Transmission
![]() | Jinma built | Jinma built |
|---|
Jinma built |
|---|
Transmission |
|---|
Dimensions
![]() | Jinma built | Jinma built |
|---|
Jinma built |
|---|
Wingin XLT-180 Tires |
|---|
Dimensions | |
|---|---|
Wheelbase | 56.7 inches
144 cm |
Length | 100 inches
254 cm |
Width | 47.4 inches
120 cm |
Height | 54 inches
137 cm |
Weight | 3,220 lbs
1460 kg |
Ground clearance | 10.8 inches
27 cm |
Photos
Recommended Implements & Sizing Guide
Engineering recommendations for Wingin XLT-180 based on its 18 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Wingin XLT-180.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Wingin XLT-180 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Wingin XLT-180.
Converted Equivalents:
Horsepower (HP)18 hp
Kilowatts (kW)13.4 kW
Metric Horsepower (PS / CV)18.2 PS
Direct Competitor Comparison
Compare Wingin XLT-180 against same-era industry alternatives in the same horsepower class.
Current Model
Wingin
Wingin XLT-180
Engine Power:Diesel (listed): 18 hp / 13.4 kW
★ Baseline Reference
International HarvesterMarket Competitor
International Harvester Type A 15HP
Engine Power:16.7
Production Years:1908 - 1911
