Yard-Man 14995
The Yard-Man 14995 is a tractor produced by Yard Man Lawn Tractors. It is equipped with a 655 cc 40 ci engine. The listed engine power is Gasoline (gross): 16 hp / 11.9 kW. Transmission: Eaton. Drive type: belt. Operating weight: 157 lbs 71 kg.
Engine Power
Gasoline (gross): 16 hp / 11.9 kW
Drive & Traction
belt
Fuel & Capacities
3 gal
11.4 L
Transmission
Eaton
Operating Weight
157 lbs
71 kg
Overview
 | 1979 - 1981
Model year 19791980-1981
Garden tractor |
|---|
Note: the Yard-Man model 14995 is the same as the MTD 995. The following data is from the 995 listing. |
|---|
Production | |
|---|---|
Manufacturer | Yard-Man (a part of MTD) |
Garden tractor | |
Yard-Man 14995 Engine | |
|---|---|
16HP Briggs & Stratton 655cc 2-cyl gasoline | |
Fuel tank | 3 gal
11.4 L |
Engine details ...  | |
Yard-Man 14995 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Tractor hitch | |
|---|---|
Rear Type | 0 OptOptional |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Weight | 1035 lbs
469 kg |
Front tire | 18x6.50 |
Rear tire | 27x9.50-15 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Engine
Note: the Yard-Man model 14995 is the same as the MTD 995. The following data is from the 995 listing. |
|---|
Engine Detail — 655 cc / 40 ci Gasoline
Manufacturer | Briggs & Stratton 400000 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled horizontal-shaft |
Displacement | 655 cc
40 ci |
Bore/Stroke | 3.44x2.16 inches
87 x 55 mm |
Power (gross) | 16 hp
11.9 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Note: the Yard-Man model 14995 is the same as the MTD 995. The following data is from the 995 listing. |
|---|
Transmission — Eaton
Transmission | Eaton |
Type | shaft-driven hydrostatic |
Gears | infinite forward and reverse (2-range) |
 | |
Dimensions
Note: the Yard-Man model 14995 is the same as the MTD 995. The following data is from the 995 listing. |
|---|
Yard-Man 14995 Tires | |
|---|---|
Lawn/turf front | 18x6.50 |
Lawn/turf rear | 27x9.50-15 |
Dimensions | |
|---|---|
Weight | 1035 lbs
469 kg |
Attachments
Note: the Yard-Man model 14995 is the same as the MTD 995. The following data is from the 995 listing. |
|---|
Attachment overview | |
|---|---|
50" mid-mount mower deck | |
Snowblower | |
Blade | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
50" Mower deck | |
|---|---|
Type | mid-mount MTD 993 |
3-blade with hydraulic lift | |
Cutting width | 50 inches
127 cm |
Drive | belt |
Weight | 157 lbs
71 kg |
Photos
Yard-Man 14995
Recommended Implements & Sizing Guide
Engineering recommendations for Yard Man Lawn Tractors Yard-Man 14995 based on its 16 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Yard Man Lawn Tractors Yard-Man 14995.
Estimated Continuous Field Runtime: 3.6 hrs
Approximately 3.6 hours of continuous field operation at ~75% rated power on a full tank (3 gal / 11.4 L).
Estimated 75% Load Fuel Burn~0.8 gal/hr (3.1 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Yard Man Lawn Tractors Yard-Man 14995 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Yard Man Lawn Tractors Yard-Man 14995.
Converted Equivalents:
Horsepower (HP)16 hp
Kilowatts (kW)11.9 kW
Metric Horsepower (PS / CV)16.2 PS
Direct Competitor Comparison
Compare Yard-Man 14995 against same-era industry alternatives in the same horsepower class.
Current Model
Yard Man Lawn Tractors
Yard-Man 14995
Engine Power:Gasoline (gross): 16 hp / 11.9 kW
★ Baseline Reference
