Yard-Man 3260
The Yard-Man 3260 is a tractor produced by Yard Man Lawn Tractors. It is equipped with a 275 cc 16.79 ci engine. The rated power output is 7 hp 5.2 kW. Transmission: Peerless 600.
Engine Power
7 hp
5.2 kW
Fuel & Capacities
Gasoline
Transmission
Peerless 600
Yard Man Lawn Tractors Yard-Man 3260 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1969 - 1972
Model year 1969-19701971-1972
Lawn tractor |
|---|---|
1969 - 1972 | |
Model year 1969-19701971-1972 | |
Lawn tractor | |
Production | |
|---|---|
Manufacturer | Yard-Man |
Lawn tractor | |
Built in Jackson, Michigan, USA | |
Yard-Man 3260 Engine | |
|---|---|
7HP Briggs & Stratton 275cc 1-cyl gasoline | |
Engine details ...  |
Yard-Man 3260 Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Front tire | 13x5.00-6 |
Rear tire | 18x8.50-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Power equipment to serve you every season published in 1970, by Yard-Man |
Engine
Engine Detail — 275 cc / 16.79 ci Gasoline
Manufacturer | Briggs & Stratton 170707 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 275 cc
16.79 ci |
Bore/Stroke | 3.00x2.375 inches
76 x 60 mm |
Power (gross) | 7 hp
5.2 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — Peerless 600
Transmission | Peerless 600 |
Type | belt-driven gear |
Gears | 3 forward and 1 reverse |
Dimensions
Yard-Man 3260 Tires | |
|---|---|
Lawn/turf front | 13x5.00-6 |
Lawn/turf rear | 18x8.50-8 |
Dimensions |
|---|
Attachments
Attachment overview | |
|---|---|
36" mid-mount mower deck | |
Snowblower | |
Blade |
36" Mower deck | |
|---|---|
Type | mid-mount Yard-Man |
2-blade with manual lift | |
Cutting width | 36 inches
91 cm |
Photos
Yard-Man 3260 tractor photo
